1.4.2.4 Dolby PLIIx
These are configuration options for Dolby PLIIx mode:
Music
PLIIx Music Options
Panorama On or Off – create a seamless wraparound surround effect.
Center Width – from 0 (off) to 7 (Phantom). This controls the balance of the main vocals in the
center and front channels for more natural sound.
Dimension – adjusts the balance of the surround sound from +7 (Full to Surround) to -7 (Full to
Front).
Movie – surround mode optimized for movie presentation.
Dolby D EX – For Dolby Digital EX content use the Dolby Digital EX decoder to produce a back
surround channel.
1.4.2.5 Auro-3D
Select Auro-3D in the Process screen to create an immersive sound experience using one of the Auro
Speaker configurations. When selected, the Auro processing works in one of two ways. Auro-encoded
input signals, natively recorded and/or mixed for an Auro-3D configuration, are decoded with the built-in
®
Auro-Codec Decoder. Alternatively, legacy content (standard stereo, surround and mono sources) may
be up-mixed using the Auro-Matic
These are configuration options for Auro-3D mode:
Preset – These are Auro-Matic® upmixer options to adjust the 3D effect for different content or
preferences.
Preset Small
Preset Medium
Preset Large
Preset Speech
Strength: 1 to 16 – Adjusts the strength of the Auro-Matic® upmixer where 16 is the highest amount
of upmixing.
Auro-3D Listening Mode:
Stereo – Plays in stereo (Left Front/Right Front)
Surround – Does not use High channels. Plays in 5.1 or 7.1 configurations, depending on
whether back surrounds are included in the speaker configuration.
Auro-3D – Full 3D audio experience. Auro content is decoded to its original speaker
configuration. Non-Auro content is upmixed to the RS20i Speaker Configuration.
Native – Decodes Auro-3D native content but does not upmix non-Auro-3D content.
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
®
upmixer module.
