Page 1 RS20i Audio Processor Installation and Operating Guide Version 1.00 Effective Date: May 2012 Document # 9301H52900 Datasat Digital Entertainment 9631 Topanga Canyon Place Chatsworth, CA 91311...
Page 2 © 2012 Datasat Digital Entertainment. All rights reserved. The content of this publication is subject to change without notice. Datasat Digital Entertainment assumes no obligation to notify you of any changes or updates. While Datasat Digital Entertainment believes this publication is accurate, due to ongoing improvements and revisions, Datasat Digital Entertainment cannot guarantee the accuracy of printed material, nor can it accept responsibility for errors or omissions.
Page 3: Regulatory Notices
RS20i Installation and Operating Guide Page 3 Document No. 9301H52900 July 2012 Record of Changes Manual Version / Description Date 0.2 October 2011 Preliminary version 0.3 January 2012 Added Bass Management 0.4 April 2012 Pre-release version 0.5 May 2012 Pre-release version. Updated legal and warranty information.
Page 4: Table Of Contents
RS20i Installation and Operating Guide Page 4 TABLE OF CONTENTS INTRODUCTION PART 1: OPERATION OPERATING RS20i – O ROCEDURES PERATIONS RONT ANEL ONTROLS AND NDICATORS RS20i P OWERING ROCESSOR AVIGATING THROUGH THE ENUS CREEN 1.4.1 DJUSTING THE OLUME CONTROL 1.4.2 XTERNAL MONITOR OLUME 1.4.3...
Page 5: Rs20I Installation And Operating Guide
RS20i Installation and Operating Guide Page 5 2.12 EQ S EQ S ET TO NOTHER 2.13 INAL DJUSTMENTS 2.14 NPUT 2.15 SING IRAC IVE TO UNE THE HEATER 2.16 RS20i P LAYBACK OUND HECK HOW-TO PROCEDURES FOR SETUP XAMPLE REATING AN...
Page 6 RS20i Installation and Operating Guide Page 6 PART 3. APPENDICES A. Connector Pin-outs B. Interface Wiring Diagrams C. RS20i Wiring and Block Diagrams D. Specifications RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 7: Introduction
Page 7 Introduction This manual explains the RS20i Audio Processor setup and operation. It contains full instructions for installing hardware and software, setting up audio playback, configuring the system, performing maintenance and troubleshooting, and setting up and operating optional functions.
Page 8: Limited Warranty
All internal control and data lines are available to expansion cards to service future user needs. To get the most out of your RS20i, we suggest that you review this manual and keep it available during system installation and initial operation.
Page 9 Entertainment hereby grants you a non-exclusive, conditional, non-transferable, revocable, limited license to use the Software solely for your own personal private purposes and solely in connection with the RS20i Audio processor. All rights not expressly granted to you are reserved by Datasat Digital Entertainment.
Page 10 2. Ownership. All right, title and interest in and to the Software, all physical copies thereof and all intellectual property embodied therein are and shall remain vested in Datasat Digital Entertainment. You do not own the Software, physical copies thereof or any intellectual property embodied therein.
Page 11 RS20i. See section 2.5.3. Power Cord to the RS20i rear panel: The power cord is the main disconnect device. It should be plugged into an easily accessible outlet with surge protection. The power cord is to be used in a minimum type SVT 18/3 rated 250 Volts AC, 10 Amps with a maximum length of 4.5 M,...
Page 12: Part 1: Operation
RS20i Installation and Operating Guide Page 12 Part 1: Operation This part of this manual contains information the user needs to operate the RS20i Audio Processor on a day-to-day basis. OPERATING RS20i – O ROCEDURES PERATIONS RONT ANEL ONTROLS AND...
Page 13: Operating Rs20I
Volume control, page 18. Select an input Touch the desired input in the bottom row of the RS20i display. If you do not see the input you want, see if the right most button says “More”. If so, tap the More button for more choices. If the desired input is still not shown, the RS20i has not been setup for this input.
Page 14: Front Panel Controls And Indicators
Power button/ USB port Figure 1: Front Panel Controls and Indicators The front panel contains the following controls and indicators for operating the RS20i. Power button: Turns the unit on and off. Gently press the power symbol on the power button cover to activate the button.
Page 15: Powering On The Rs20I Processor
1.3 Powering ON the RS20i Processor Warning: Before powering on the RS20i for the first time, verify that the correct input voltage has been selected at the rear panel power entry module. Incorrect input voltage setting will damage the RS20i.
Page 16: Navigating Through The Menus
Navigating through the Menus Since the RS20i is equipped with a touch screen display, you can navigate easily through the menus by touching any button with your finger. A non-abrasive stylus that will not scratch the screen can also be used if you prefer.
Page 17: The Home Screen
When the system has finished booting up, the Home Screen will appear, as shown in the above example. Your Home Screen may look somewhat different, due to user-configurable channel names and audio inputs. The Home Screen of the RS20i provides one-touch access to the following features: Volume Control /Mute Audio Inputs...
Page 18: Adjusting The Volume Control
To mute the volume control, touch the Mute button. The button text will turn red. Unmute the RS20i by touching the mute button again, changing input level, or changing inputs. If in the Home Screen, increasing the volume control using the knob will also unmute.
Page 19 RS20i Installation and Operating Guide Page 19 Figure 7. Monitor Volume Touch the small button to select a channel for monitoring Figure 8. Monitor Mix Select channel(s), then touch the + or – button to adjust volume from 0 to 10.
Page 20: Manual Automation
RS20i Installation and Operating Guide Page 20 1.4.3 Manual Automation The Automation button opens the automation manual control screen. Figure 9. Automation Manual Control screen This screen allows for direct control of automation events in any order, at any time. Once your installer has linked automation events to macros, and macros have been assigned to buttons, you can trigger any macro by pressing its button on this screen.
Page 21: Troubleshooting (Operation)
See Powering ON the RS20i Processor, page 15. If the RS20i is mounted in a rack and a breaker is used for the rack, make sure the breaker is ON. Verify the surge protector is powered and is working.
Page 22: Over Temperature Alert
RS20i chassis. Check that there is nothing obstructing these air vents. Be sure that the fan is spinning (you will feel air blowing out of the RS20i from the fan). If the vents are clear and the fan is spinning, yet the temperature alert does not stop, call your installer for service.
Page 23: Part 2: Installation And Setup
RS20i Installation and Operating Guide Page 23 Part 2: Installation and Setup This part of this manual contains information the installer needs to set up and configure the RS20i Audio Processor. PART 2: INSTALLATION AND SETUP INSTALLATION AND SET UP ......................
Page 24: Rs20I Installation And Operating Guide
RS20i Installation and Operating Guide Page 24 4.2.1 RS20i S ....................56 PDATING OFTWARE 4.2.2 ................58 AVING AND ESTORING ONFIGURATION ILES 4.2.3 ........................... 59 CCESS ONTROL 4.2.4 ..........................62 4.2.5 ..........................62 YSTEM 4.2.6 ................63 ERSION ERIAL UMBER ADDRESS 4.2.7...
Page 25: Installation And Set Up
2.1 Installation Checklist This checklist summarizes the installation and setup procedures for the RS20i. Table 2: RS20i Installation and Setup Completed...
Page 26 RS20i Installation and Operating Guide Page 26 Completed Task Description Refer to: Remove feet from RS20i (if needed for Installing/Removing Feet, page 30 rack clearance) CONNECT CABLING: Power Cable Audio input cables to RS20i (Depends on audio sources) Audio output cable from RS20i Analog Appendix B, Interface Wiring Diagrams.
Page 27: Unpacking System Components
2.2.1 Preliminary Inspection Note: Before installing the RS20i unit, take a complete inventory of system components to minimize problems or questions during installation. Additionally, save all packing materials until installation is complete in case you need to return parts to the factory.
Page 28 RS20i Installation and Operating Guide Page 28 14 15 16 17 Figure 11. RS20i Rear Panel Table 3. RS20i Rear Panel Connections ITEM DESCRIPTION ITEM DESCRIPTION Power Entry Module/Power Switch Digital Audio In (CH 1 – 8) – DB25F Option Card Slots (3) Digital Audio In (CH 9 –...
Page 29: Mounting And Connection
When using the Digital Out, make sure the input device is set to the same sample frequency as the RS20i and that its clock source is set to input. Sample rate choices are 48kHz, 96kHz, and 192kHz. Select the highest rate supported.
Page 30: Rack Mount Installation
Note: The RS20i ships with feet installed. These may need to be removed for rack space clearance Install the rack ears onto the RS20i by removing three 8-32 pan head screws on each side of the RS20i and using them to attach the rack ears.
Page 31: Power Supply
CAUTION: DOUBLE POLE/NEUTRAL FUSING Open the fuse compartment door. A small flat blade screwdriver may be used to release the door. Protect the RS20i metal finish, from damage by the screwdriver, with a rag or other soft item. Soft rag Screwdriver Figure 15.
Page 32: Navigating The Menus
(usually to scroll through a list or to increase/decrease values): Note: When using a laptop to VNC into the RS20i, use the up and down arrows to mimic the scrolling action of the front panel adjustment knob.
Page 33: About Inputs
The buttons along the bottom of the RS20i Home screen are the default inputs or inputs that have been created by the installer for a particular application. Each input consists of a set of discrete settings: an Input Source, Input Options, EQ settings, and Output preset, as illustrated below (Figure 18).
Page 34: Creating An Audio Input
RS20i Installation and Operating Guide Page 34 In the Audio Input Setup screen, five options appear along the bottom: Input Source, Input Options, Audio EQ Setup, Output preset, and Audio Levels. Setup (System) > Inputs Figure 19. Audio Input Setup Screen 2.7.1 Creating an Audio Input...
Page 35: Factory Presets
Third Octave EQ: Calibrated adjustment made by qualified installer Parametric Equalization: Calibrated adjustment made by qualified installer 2.8 Factory Presets The RS20i factory settings include inputs for Digital Cinema and Stereo as described in the table below. Table 4. RS20i Factory Presets Input...
Page 36: Default Eq
RS20i Installation and Operating Guide Page 36 Table 5. RS20i Preset Inputs Input Name Signal Source Analog Analog 8Chan Digital 1 Digital Ch: 1-8 HDMI 1 HDMI Port 1 HDMI 2 HDMI Port 2 SPDIF S/PDIF Coax Stereo 1 Stereo1 L/R...
Page 37: Rs20I Configuration And Setup
Audio alignment will be performed differently depending on whether the (optional) Dirac Live Theater Setup application or the RS20i 1/3 Octave EQ room tuning function is used. In fact, Dirac Live can be used in conjunction with 1/3 Octave EQ, in a case where Dirac Live is used to tune the room and then the 1/3 Octave EQ is used afterwards to make some changes to specific frequencies.
Page 38: Theater Equipment Check
EQ (Audio) alignment. 2.9.4 Assign Channels on RS20i After installing the RS20i and connecting the cabling for inputs and outputs, the next step is to assign channels. The RS20i allows custom defined channel names for the input channels. The input channels are named through the Channel Names screen.
Page 39 RS20i Installation and Operating Guide Page 39 Setup (System) > Inputs > Output Preset > Channel Names Figure 20. Channel Names Screen When channel assignments are complete, you can eliminate the unassigned channels so they do not appear on the main screen. Turn off the VU indicator for unused channels.
Page 40: Hearing Impaired Output
2.9.6 Verify Channel Assignments in Theater On the RS20i, select a channel and turn on Pink Noise. In the theater, verify that the Pink Noise output is coming from the correct loudspeaker(s). Do this for all channels. For details, see Audio Levels, page 103.
Page 41: Sound Level Calibration Using 1/3 Octave Eq
The intent is to show the RS20i functions that are relevant to audio alignment. Caution: Before proceeding with the room equalization, it is imperative that the loudspeaker and crossover systems be properly aligned.
Page 42: Set Levels To Establish A Baseline
RS20i Installation and Operating Guide Page 42 Note: Be sure to open the curtains (if any) at the front of the theater. Figure 23. Suggested Microphone Placement in Small Theater Use a single calibrated microphone located in the center seating position.
Page 43: Set The Eq
Dirac Live to Tune the Theater, page 4 8. The RS20i contains a full suite of 1/3 Octave EQ filters that are “traditional” cinema processor filters. If using RS20i 1/3 Octave EQ, complete the following steps. Setup (System) > Inputs > Audio EQ Setup > Third Octave EQ Figure 24.
Page 44 Use the RTA on the RS20i (Third Octave EQ screen) with the mic or multiplexer plugged into the RS20i rear panel, or use a separate RTA (in the theater) with the mic or multiplexer plugged into the RTA, which plugs into your laptop.
Page 45 RS20i Installation and Operating Guide Page 45 Setup (System) > Inputs > Audio EQ Setup > Third Octave EQ > RTA Options > XCurve Display Figure 25. XCurve Display at +/- 6dB Scale 2.10.2.2 A note about Third Octave EQ The RTA input source is also a useful tool to examine the effects of the settings applied.
Page 46: Subwoofer Eq - Parametric Eq
2.11 Subwoofer EQ – Parametric EQ The RS20i features Parametric EQ on every channel. Parametric EQ is an optional adjustment and is in addition to 1/3 Octave EQ. It is only available with low frequencies and offers more control than 1/3 Octave EQ.
Page 47: Final Adjustments
RS20i Installation and Operating Guide Page 47 Setup (System) > Inputs > Audio EQ Setup > Edit EQs Figure 28. Copy EQ Settings Use the Copy EQ function, accessible from the Edit EQs menu to copy the EQ set. Select the Copy EQ From set (select from the pulldown), then in the to EQ field, enter a new name for the EQ set, then click the Copy button.
Page 48: Using Dirac Live To Tune The Theater
2.15 Using Dirac Live to Tune the Theater See the Dirac Live Theater Setup Guide for detailed instructions. The Dirac Live application is a separate tool, available from Datasat Digital Entertainment but not supplied with the RS20i processor. 2.16 RS20i Playback Sound Check After installing and setting up the unit—or doing a maintenance check—it is a good idea to...
Page 49: How-To Procedures For Setup
View RS20i System information See 4.2.5 System Info, page 62. Update RS20i software See 4.2.1 Updating Your RS20i Software, page 56. 3.1 Example: Creating an Input Prior to creating an input, it is necessary to identify the following: Input source...
Page 50: Setup Menus
Setup Menus On the next four pages, you will find a menu diagram for the RS20i. This chapter contains a detailed description of all the screens under the "Setup" selection of the home screen. Refer to section 1.4 for all operations under the "Home"...
Page 51 RS20i Installation and Operating Guide Page 51 RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 52 RS20i Installation and Operating Guide Page 52 RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 53 RS20i Installation and Operating Guide Page 53 RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 54 RS20i Installation and Operating Guide Page 54 RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 55: The Setup Button
Selecting the button, after first powering up the RS20i, will display the System Setup screen. This will provide access to the Setup menus. In the next section, we will discuss in detail the options available through the system setup screen.
Page 56: Updating Your Rs20I Software
4.2.1 Updating Your RS20i Software There are two ways you can update your software. The first way, is to connect to the servers at Datasat Digital Entertainment to select and install the update. This requires that the RS20i is connected to the Internet.
Page 57 The current version of software loaded on the RS20i is displayed under Current on the right side of the screen. The highlighted software version, will display under Selected on the right side of the screen.
Page 58: Saving And Restoring Configuration Files
Note: Always be careful, as any existing Master Configuration file on the USB will be overwritten when you save another one. The standard configuration is specific to one RS20i. This contains the unique third octave EQ, DiracEQ, inputs, output preset, automation, and global configurations needed for that RS20i. The standard configuration file can only be loaded back onto the same RS20i.
Page 59: Access Control
Save Master Config Save RS20i configuration to USB device as MASTER configuration, which may be loaded onto other RS20i units. This will erase from the USB device any existing MASTER configuration. Save Diagnostic Info Save RS20i Diagnostic information to the USB device to facilitate troubleshooting.
Page 60 Note: When removing password protection, if no hyphen is entered (blank selection), the RS20i will continue to ask for a password to enter the setup menus. In that case select the OK button to enter the setup menus without entering a password.
Page 61 Selecting this option will improve VNC performance for some clients. 4.2.3.4 Identity Three text fields may be entered for identification of the RS20i. These are labeled “Screen”, “Info1”, and “Info2”. These fields may be used to enter useful information, such as the installer name.
Page 62: View Log File
The log file is helpful for debugging by Datasat Digital Entertainment staff. You may be asked by the Datasat staff to save the log files on the USB Flash drive, to send for troubleshooting purposes.
Page 63: Version, Serial Number, And Mac Address
RS20i Installation and Operating Guide Page 63 Figure 38. System Info Screen 4.2.6 Version, Serial Number, and MAC address The yellow portion displays software version and build date, unit serial number, and MAC address. 4.2.7 System Monitor The pink portion displays the internal board temperatures.
Page 64: Inputs
RS20i Installation and Operating Guide Page 64 4.3 Inputs Setup (System) > Inputs Figure 39. Input Setup Screen 4.3.1 Current Input Select the input you wish to modify from the drop-down list of installed inputs. Touch the drop down list to open it, then use the adjustment knob to scroll the list in cases where there are several inputs.
Page 65: Startup Input
Press the Copy button to complete the process, or press Cancel to quit. Copy Preset to Input – Select one of the pre-installed Inputs in your RS20i and use it as a template for a new one. Select the input you wish to copy from by selecting it from the RS20i Installation &...
Page 66: Assign Input Buttons
RS20i Installation and Operating Guide Page 66 drop down box. Then, touch the “to Input” box to bring up the virtual keyboard and enter a name for the new input. Press the Copy button to complete the process, or press Cancel to quit.
Page 67 RS20i Installation and Operating Guide Page 67 Button location 1 Button location 8 Figure 44. Home Screen Input Button Locations 4.3.4.1 Enable “More” Button When the Enable “More” Button is not selected, the Home screen will display the eight assignable input buttons on the bottom of the screen (see Figure 44). When the Enable “More”...
Page 68: Input Source
If HDMI is selected, touching the button again cycles the selection from HDMI-1 to HDMI-4. See Table 12 (below) for a description of where input channels are mapped within the RS20i. Figure 46. Input Source Screen RS20i Installation & Operating Guide...
Page 69 Processor Channel 1 If a DTS or Dolby Digital bitstream is detected and decoded, the decoded stream will be routed to the first eight channels internally on the RS20i. See section 4.3.6.7 Decoder Setup for more information. RS20i Installation & Operating Guide...
Page 70: Input Options
RS20i Installation and Operating Guide Page 70 4.3.6 Input Options The Input Options screen allows changes to Global Delay, Extended Surround Options, Stereo Level and Routing, Mic Level and Routing, Matrix and Routing, Decoder Setup, and Digital Cinema Options. It also provides feedback on the current Audio input.
Page 71 Subtract surround distance from the screen distance, and add 20 (screen - surround + 20). The result is the surround delay in milliseconds. After setting the surround delay in the RS20i, verify the setting by listening to a familiar soundtrack. The action on-screen should match sound in the theater.
Page 72 RS20i Installation and Operating Guide Page 72 4.3.6.2 Extended Surround Options Setup (System) > Inputs > Input Options > Extended Surround Options Figure 49. Extended Surround Options The Extended Surround Options screen is available with input sources: Stereo, Mic Pre, Analog, and Digital 9-16.
Page 73 RS20i Installation and Operating Guide Page 73 Figure 50. Stereo Level & Routing Adjust the input levels of Stereo1 and Stereo2 by selecting the box under L or R and turning the volume control knob. Inputs can be sent to:...
Page 74 RS20i Installation and Operating Guide Page 74 4.3.6.4 Mic Level and Routing This screen is available for the Mic Pre input source only. Setup (System) > Inputs > Input Options > Mic Level and Routing Figure 52. Mic Level & Routing Adjust the Mic gain by selecting the box under gain and turning the volume control knob.
Page 75 RS20i Installation and Operating Guide Page 75 4.3.6.5 Matrix and Routing This screen is available for Digital 1-16 and Digital 1-8 input sources only. Setup (System) > Inputs > Input Options > Matrix and Routing Figure 53. Matrix & Routing Enable Matrix Decoder.
Page 76 Setup (System) > Inputs > Input Options > Decoder Setup Figure 55. Decoder Setup The RS20i accepts a DTS, DTS-HD, DTS-HDMA or Dolby Digital audio stream from a DVD, Game Console, Satellite link or other source device. The Encoded bit stream is automatically detected and decoded internally by the RS20i software.
Page 77: Operation
The RS20i monitors the selected input signal to determine the type of audio signal received. If a DTS, DTS-HD or Dolby Digital bitstream is detected, the RS20i decodes the audio and places it on the first 8 channels (see Table 13).
Page 78: Eq Setup
RS20i Installation and Operating Guide Page 78 Speaker Configuration 5.1 – When playing 6.1 audio the back surround channel information will be mixed into the left surround and right surround channels. 7.1 – When playing 6.1 audio the back surround channel information is placed on both back surround channels: 7 and 8.
Page 79 RS20i Installation and Operating Guide Page 79 4.3.7.1 Current Audio EQ This drop-down list allows you to select from the list of available EQ setups. The selection will become the current audio equalization setup. 4.3.7.2 Edit EQs Selecting the Edit EQs button from the Audio EQ Setup screen will open the screen below.
Page 80 4.3.7.3 Dirac Optimization The Dirac Live setup procedure must be used to copy Dirac configuration setup files to the RS20i before this screen becomes functional. Ignore this screen if you are not using Dirac Live software to setup the RS20i.
Page 81 RS20i Installation and Operating Guide Page 81 Corner Frequency Adjust Current Input and Volume Current audio level and 0dB reference Figure 59. 1/3 Octave EQ Screen Channel Number Selection – Touch the Chan button to bring up a display of all sixteen channels.
Page 82 If Mic Power is ON, it remains ON when you leave this screen and go to other screens. However, Mic Power is automatically disabled when the RS20i resets. This Mic Power setting is independent of the Mic power that is part of Input.
Page 83 RS20i Installation and Operating Guide Page 83 Corner Frequency adjustments – Touch the corner frequency box for treble or bass and adjust using the adjustment knob. The corner frequency for bass can be set from 50Hz to 300Hz. The corner frequency for the treble can be set from 1.5kHz to 12kHz. The corner frequency cannot be set for individual channels—the setting affects all channels in the...
Page 84 RS20i Installation and Operating Guide Page 84 Figure 63. Clear EQ on selected channel Clear EQ on all channels clears third octave, bass, treble and parametric filters on all channels. Figure 64. Clear EQ on all channels RS20i Installation & Operating Guide...
Page 85: Output Preset
RS20i Installation and Operating Guide Page 85 4.3.8 Output Preset Setup (System) > Inputs > Output preset Figure 65. Output Preset Setup Screen 4.3.8.1 Current Output Preset The current output preset is displayed in the drop-down box under the label “Current Output Preset”.
Page 86 4.3.8.3 Channel Names Depending how the RS20i is connected, sixteen channels are available. Channel assignments can be different in other output presets. The top title bar displays the current input and output preset. Note: In general, the default assignments must be preserved for the first 6 channels in order to maintain compatibility with the HDMI input channel assignments, and with the Hearing Impaired output channel.
Page 87 RS20i Installation and Operating Guide Page 87 The output preset channel name refers to the input channel only. The channel name for the output channel (if used) will be a combination of the corresponding input and the crossover letter (for example, Left-H).
Page 88 RS20i Installation and Operating Guide Page 88 4.3.8.4.1. Signal flow When implementing crossovers or implementing different internal routing on the RS20i, the input channel numbers do not match the output channel numbers. The following explanation clarifies how the menus operate regarding the channel numbers.
Page 89 M, H, and 0-9. This is used for reference for the output channel and has no functional purpose at this time. 4.3.8.4.4. Example Crossover Setup When setting up the RS20i crossovers, you will need to identify the speaker model used and obtain its technical specifications. Speaker technical specifications can usually be found on the manufacturer’s web site.
Page 90 RS20i Installation and Operating Guide Page 90 Low Frequency Figure 70. Example – Low Frequency Crossover Setup As shown in Figure 70, set output channel for the low frequency driver. To make changes select a box by touching it and use the volume control to change its value.
Page 91 RS20i Installation and Operating Guide Page 91 Mid Frequency Figure 71. Example – Mid Frequency Crossover Setup As shown in Figure 71, set output channel for the mid range driver. Make sure the input channel is still set to (or left channel, remember, left = channel 1 in the example).
Page 92 RS20i Installation and Operating Guide Page 92 Figure 72. Example – High Frequency Crossover Setup As shown in Figure 72, set output channel for the high range driver. Make sure the input channel is still set to (or left channel, remember, left = channel 1 in the example).
Page 93 RS20i Installation and Operating Guide Page 93 Figure 73. Example – Crossover Setup 4.3.8.5 Channel Delays Setup (System) > Inputs > Output preset > Channel Delays Figure 74. Channel Delays Delays can be set for each of the 16 channels. Touch the Delays box under the desired channel. Enter the delay by dialing in the correct value using the front panel adjustment knob.
Page 94 RS20i Installation and Operating Guide Page 94 Figure 75. Dividing the Left Channel There is one configuration for each of the channel pairs, and a separate configuration for the center channel. There are four configurations for speakers or speaker pairs that can be made:...
Page 95 RS20i Installation and Operating Guide Page 95 The figure below illustrates the LFE input being mixed with the left channel. Each channel works in a similar fashion so the LFE channel can be inserted into as many speakers as desired.
Page 96 RS20i Installation and Operating Guide Page 96 a. Large– (default) select this option if the center speaker can handle all frequencies. b. Small – Select small if you wish to cross the signal with the subwoofer(s). Then select the crossover frequency and slope for the center speaker. The high-pass to the center speaker at the crossover frequency may be disabled if desired.
Page 97 RS20i Installation and Operating Guide Page 97 d. Phantom Center. Use this if there is no center speaker installed. This divides the center channel between the left and right speakers. The offset can be adjusted. 11. Return to the Bass Management Setup screen and tap on Left or Right speaker. This selects the speaker option for both left and right front speakers: a.
Page 98 RS20i Installation and Operating Guide Page 98 Setup (System) > Inputs > Output Preset > Bass Management Figure 77. Bass Management Setup Screen Controls Description Enable Bass Global enable for all bass management functions. Management Subwoofer Configuration Select number and positions for subwoofers. See subwoofer configuration options table below. Full Range to Sub Select to remove all low pass filters to the subwoofers. Left Speaker Tap on left speaker to configure left/right speaker. Right Speaker Tap on right speaker to configure left/right speaker. Center Speaker Tap on center speaker to configure center speaker. Left Surround Speaker ...
Page 99 RS20i Installation and Operating Guide Page 99 Subwoofer Configuration The subwoofer configuration option configures the bass management with the number of sub-woofer channels between 0 and 4. Subwoofer Configuration Number of Subwoofer Channel Assignments Options Subwoofers No Subs None Mono...
Page 100 RS20i Installation and Operating Guide Page 100 Table 14. Speaker Options using one or more Subwoofers Table 15. Speaker Options using no subwoofers HP/LP Filter The slope can be set at either 12dB/octave or 24dB/octave. The cutoff frequency can be set between 31Hz and 160Hz.
Page 101 RS20i Installation and Operating Guide Page 101 Table 14: Speaker Option with One or More Subwoofers Controls Applicable Diagram Description Channels (replace center with applicable channel) Large All No modifications to (L/R, C, channel LS/RS, RSL/RSR) . Small, All Crossed with LFE enable high (L/R, C, High pass on channel audio pass LS/RS, RSL/RSR) ...
Page 102 RS20i Installation and Operating Guide Page 102 Table 15: Speaker Options with No Subwoofers Diagram Description Applicable Controls (replace center with applicable Channels channel) Large All LFE added to audio channel (L/R, C, LS/RS, RSL/RSR) Small, All No LFE added to audio enable high (L/R, C, channel pass LS/RS, RSL/RSR) High pass on channel ...
Page 103: Audio Levels
RS20i Installation and Operating Guide Page 103 4.3.9 Audio Levels Setup (System) > Inputs > Audio Levels Select channel(s) Figure 79. Audio Levels The Audio Levels screen is used for these functions: Set the levels. You can turn on the pink noise on any single channel to check and adjust the level.
Page 104 (blue). Digital volume should be enabled only if the system is using the digital output on the RS20i. Note: Channels 1 through 16 on this screen refer to the input channels. In cases where the input is routed to a different output channel, the control represents only the input channel path.
Page 105: Network
RS20i Installation and Operating Guide Page 105 4.4 Network Setup (System) > Network Figure 80. Network Screen The Network screen displays the current network mode and IP address. It also displays whether or not the network connection is currently up or down. Use it to change between dynamic and static IP addressing.
Page 106: Network Connection Setup Procedure
1. What type of network are you connecting to? Dynamically Assigned IP Address (DHCP) DHCP means that when the RS20i is connected to the network, an IP Address is automatically assigned to it. The boxes for IP Address, Mask, Broadcast Addr, Gateway and DNS Server 1 are filled in.
Page 107 Go to Setup (System)…Network….Net Diag and enter the IP address of the other network device in the <Select address> box. Press Ping Test and see the message. ‘OK’ means the RS20i is connected to the same network. ‘Fail’ means that the network connection to the other device is not correct.
Page 108 Some local area networks (LANs) have a connection to the internet, some do not. In order to update the RS20i from the Datasat server, there must be an internet connection. To test this, select ‘Net Diag’ and use the Ping Test utility. Select the destination ‘Datasat’ in the ‘Dest:’...
Page 109 RS20i Installation and Operating Guide Page 109 Use the Dest: box on the Ping Test to check the ‘gateway’ is ‘OK’. If there is PC connected to the same LAN, open an internet browser and go to any public web site such as http://www.datasatdigital.com...
Page 110: Automation
RS20i Installation and Operating Guide Page 110 Optionally - if there are other desktop PCs and laptops that normally connect to the network, for example the service tech’s laptop or the manager’s laptop, these will normally request an available IP address from the DHCP server automatically. To allow this, the ‘DHCP range’ must be defined: DHCP range 192.168.0.220 –...
Page 111: Events
RS20i Installation and Operating Guide Page 111 4.5.1 Events Setup (System) > Automation > Events Figure 83. Automation Events Screen Existing events will be displayed in the Automation Events screen. The front panel adjustment knob must be used to move the selection bar to an existing event for editing. The list will scroll when needed going past the end when there are more events in the list.
Page 112 RS20i Installation and Operating Guide Page 112 4.5.1.1.2. Event Type When an event is first added the event type defaults to “No Event”, this means the event type is not configured and should be replaced with one of the other event types.
Page 113 RS20i Installation and Operating Guide Page 113 o Conditional – The action is executed conditionally based on a previous event. Action Type: o Delay – Delay is set in milliseconds with a range of 0-10000ms (10 seconds) o GPO – Select a GPO to set (GPO 1-20 or Projector) by touching the dropdown menu next to “Set”.
Page 114 RS20i Installation and Operating Guide Page 114 Figure 88. Automation Edit Action screen – Conditional GPO Use descriptive variable names. Try to keep variable names short and simple. The conditional action will not work as expected if the name does not match exactly.
Page 115 Touch OK when finished, or touch Cancel to cancel this task. Fire Event A Fire event will shut down the RS20i audio and display a popup on the home screen that says “Fire!”. The RS20i audio and menus are disabled until the unit is reset from the back power button.
Page 116: Macros
RS20i Installation and Operating Guide Page 116 Fire event is activated by an event that sets the variable FIRE to TRUE (In the Automation Edit Action screen set Action Type = Set Variable, Variable Name = FIRE, and Set to = TRUE).
Page 117: Automation Buttons
RS20i Installation and Operating Guide Page 117 Continue to define the Macro script by adding Actions before or after existing Actions (highlight existing actions using the front panel adjustment knob). Existing Actions may also be highlighted and edited (select the “Edit” button) or removed (select the “Remove” button).
Page 118: Automation Test Screen
Touch OK when finished, or touch Cancel to cancel this task. 4.5.4 Automation Test Screen The Automation Test Screen provides an easy way to test that the automation signals to and from the RS20i are correctly wired and operational. Setup (System) > Automation > Test Figure 94. Automation Test RS20i Installation &...
Page 119: Maintenance And Troubleshooting
The input indicator turns green when there is a low signal applied to the pin. To verify that the RS20i is properly receiving an input from an external source you would need to make the external device send a low signal on that pin. Then confirm that the signal is received by the RS20i by checking if the corresponding circle turns green.
Page 120 (these steps are much like opening a combination padlock): Cycle the power on the RS20i from either the front or rear panel switch. You will only be able to enter touch screen calibration mode for 2 minutes after recycling the power.
Page 121: Error Messages
Figure 97. USB Device Not Found If you encounter this error message, be sure you have inserted a USB device into the RS20i. If a device is present, it may be malfunctioning. Replace the USB device with another to see if the problem is resolved.
Page 122: Error Booting The Rs20I
************************************************************ insert USB memory stick with rs20 image ************************************************************ To solve this problem, reboot the RS20i, making sure nothing is in contact with the touch screen during the boot-up process. RS20i Installation & Operating Guide Document # 9301H52900 Ver. 1.00...
Page 123 RS20i Installation and Operating Guide Version 1.00 Appendix A. Connector Pin-outs This appendix lists the pin-out of all of the connectors on the back panel of the RS20i Audio Processor. Figure 1. RS20i Rear Panel AUTOMATION GPIO – DB25F Description...
Page 124 RS20i Installation and Operating Guide Version 1.00 CONTROL (RS232)– DB9F Description Data out - TXD Data in - RXD Connected to pin 6 Chassis GND Connected to pin 4 Connected to pin 8 Connected to pin 7 N/C = No connection SERVICE PORT (RS232)–...
Page 125 RS20i Installation and Operating Guide Version 1.00 HDMI IN 1-4, OUT – HDMI Description HDMI TMDS Data 2 (+) TMDS Data 2 (Shield) TMDS Data 2 (-) TMDS Data 1 (+) TMDS Data 1 (Shield) TMDS Data 1 (-) TMDS Data 0 (+)
Page 126 RS20i Installation and Operating Guide Version 1.00 DIGITAL AUDIO IN (CH 1 – 8) – DB25F Description Chassis Ground AES 1/2 - AES 3/4 + Chassis Ground AES 5/6 - AES 7/8 + Chassis Ground Chassis Ground Chassis Ground AES 1/2 +...
Page 127 RS20i Installation and Operating Guide Version 1.00 DIGITAL AUDIO OUT (CH 1 – 8) – DB25M Description Chassis Ground AES 1/2 - AES 3/4 + Chassis Ground AES 5/6 - AES 7/8 + Chassis Ground Chassis Ground Chassis Ground Word Clock Out...
Page 128 CHANNEL 4 (+) N/C = No connection Note: RS20i Analog channels are designed to be balanced, not single ended, for highest sound quality. If wiring single ended, wire only to (+) and ground. The (-) side of the channels should not be connected.
Page 129 CHANNEL 12 (+) N/C = No connection Note: RS20i Analog channels are designed to be balanced, not single ended, for highest sound quality. If wiring single ended, wire only to (+) and ground. The (-) side of the channels should not be connected.
Page 130 CHANNEL 4 (+) N/C = No connection Note: RS20i Analog in and out channels are designed to be balanced, not single ended, for highest sound quality. If wiring single ended, wire only to (+) and ground. The (-) side of the channels should not be connected.
Page 131 RS20i Installation and Operating Guide Version 1.00 Appendix B: Interface Wiring Diagrams Interface Wiring Diagrams Appendix B: Document #: 9301H52900 Ver. 1.00...
Page 132 RS20i Installation and Operating Guide Version 1.00 Interface Wiring Diagrams Appendix B: Document #: 9301H52900 Ver. 1.00...
Page 133 RS20i Installation and Operating Guide Version 1.00 Interface Wiring Diagrams Appendix B: Document #: 9301H52900 Ver. 1.00...
Page 134 RS20i Installation and Operating Guide Version 1.00 Interface Wiring Diagrams Appendix B: Document #: 9301H52900 Ver. 1.00...
Page 135 RS20i Installation and Operating Guide Version 1.00 Appendix C: RS20i Wiring and Block Diagrams thru 3 HDMI 1.4a Dolby/DTS Decoder Appendix C: Block Diagrams Document #: 9301H52900 Ver. 1.00...
Page 136 RS20i Installation and Operating Guide Version 1.00 Appendix D: RS20i Product Specifications Digital Audio Decoders Dolby Dolby AC3 DTS-HD Master Audio / DTS ES / DTS 5.1 / Neo:6 Signal Inputs HDMI Audio & Video Inputs Audio Channels: Up to 8 (LPCM, DTS-HD Master Audio & Dolby AC3) Connectors: 5 HDMI connectors (4 switched as inputs and 1 as output) HDMI V1.4a compliant digital audio with video pass-thru...
Page 137 RS20i Installation and Operating Guide Version 1.00 Connectors: Two DB25 Male (Ch1-8 and Ch9-16) Digital Format: AES/EBU Sample Rates: 48kHz, 96kHz and 192kHz Analog Audio Outputs Channels: 16 (fully routable as to input), common mapping with Digital Outputs Balanced (can be connected unbalanced or single ended) Connectors: Two DB25 Male (Ch1-8 and Ch9-16) Level: 300mV with Volume at -15.0, +26dBu max (balanced)
Page 138 RS20i Installation and Operating Guide Version 1.00 Audio Delays Individual Channel Delays 0 - 1000ms Global Delay 0 –1000ms Note: Total delay per channel not to exceed 1000ms Automation Inputs/Outputs Connector: DB25 16 bi-directional GPIO’s, optically isolated External +5v@140mA Management...
Page 139 RS20i Installation and Operating Guide Version 1.00 UL CB Scheme FCC Part 15, subpart B Class A RoHS compliant E&OE All product specifications subject to change without notice. All trademarks are properties of their respective owners. Appendix D: RS20i Product Specifications...
