Datasat RS20i Installation And Operating Manual page 44

Setup > Inputs > Input Source
•
If Stereo is selected, touching the button again toggles the selection between Stereo1 and Stereo2.
•
If Digital is selected, touching the button again toggles the selection between Digital Ch: 1 > 8,
Digital Ch 9 > 16, Digital Ch: 1-2, Digital Ch: 9-10 and Digital Ch: 1 > 16.
Table 7 shows where input channels are mapped within the RS20i.
Table 7. Input Source Mapping
INPUT
Analog 8 Channel
Stereo1 L/R
MIC Pre
Digital Channel 1
Digital Channel 1
Digital Channel 9
TosLink A
TosLink B
S/PDIF Coax
HDMI
HDMI Input
1. If a DTS or Dolby Digital bitstream is detected and decoded, the decoded stream will be routed to
the first eight channels internally on the RS20i. See section 4.3.6 Surround Decoder Setup on
page 48 for more information.
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Figure 25. Input Source Screen
16
8
16
Maps to...
OUTPUT
Processor Channel 1
Processor Channel 1, 2 (L, R)
Processor Channel 3 (Center)
Processor Channel 1
Processor Channel 1
Processor Channel 1
Processor Channel 1
Processor Channel 1
Processor Channel 1
Processor Channel 1
HDMI Audio/Video Input port selection
Document # 9301H52900 Ver. 1.02
Page 44
8
16
8
8
2
1
2
1
2
1
8
