Datasat RS20i Installation And Operating Manual page 41

Table 6. Edit Input Presets
Function
Copy Input Preset
Create Input
Preset
Rename Input
Preset
Delete Input
Preset
RS20i Installation & Operating Guide
RS20i Installation and Operating Guide
Description
Use an existing Input Preset as a template for a new one.
Select the Input Preset you wish to copy from by selecting it from the Copy
drop down list.
Then, touch the To box to bring up the virtual keyboard and enter a name for
the new Input Preset.
Press the Copy button to complete the process, or press Cancel to quit.
Select one of the pre-installed Input Presets in your RS20i and use it as a
template for a new one. The Input Preset is created with the Input Source as
described by the Input Preset name, and retains the Current EQ Setup and
current Output Preset.
Select the Input Preset from the Create, using template drop down box.
Then, touch the To box to bring up the virtual keyboard and enter a name for
the new Input Preset.
Press the Create button to complete the process, or press Cancel to quit.
Give an existing Input Preset a new name.
Select an existing Input Preset from the drop-down list on the right side of
the screen.
Touch the To box to bring up the virtual keyboard and enter a new name for
the Input Preset.
Press the Rename button to complete the process, or press Cancel to quit.
Note: Renaming the Input Preset will also change any references to that Input
Preset, such as the button assignment or the Input Preset used on Macros and
Events.
Select an existing Input Preset from the Delete drop-down list on the right
side of the screen.
Press the Delete button to complete the process, or press Cancel to quit.
Note: An Input Preset may not be deleted if it is referenced by a Button
Assignment or an Automation Event. A pop-up message will appear if the Input
Preset cannot be deleted. In that case, references to that Input Preset must first
be removed in order to delete the Input Preset.
Page 41
Document # 9301H52900 Ver. 1.02
