Post processor modes include:
•
DTS NeoX
•
Dolby PLII/Dolby PLIIx
•
Dolby PLIIz
•
Auro-3D (only available if the Auro-3D option has been purchased)
•
None
Note: The selection of Post processor modes available will vary depending on the speaker
configuration setup in Bass Management.
1.4.2.1 DTS Neo X
DTS Neo:X is available for all speaker configurations except 2.0 and 2.1 Neo:X takes source content from
2 channel, 5.1 or 7.1 content and expand it to 7.1 plus front wide and front high speakers, depending on
which speakers are enabled in the RS20i speaker configuration.
These are configuration options for DTS NeoX mode:
Cinema – Neo:X Cinema should be used for a movie presentation.
Music – Neo:X music mode should be used for a music presentation.
Game – Neo:X Game may be used for gaming.
Option: Make sub from 2ch content: Extract SW Off/On – If set ON, when the unit receives 2-
channel source content a subwoofer channel will be created from the low frequencies of the content.
If set OFF, there will be no subwoofer output with 2-channel source content.
1.4.2.2 Dolby PLIIz
Dolby PLIIz is available for speaker configurations that include HL/HR speakers. It is used to expand 2-
channel, 5.1, or 7.1 up to 9 available speakers in the speaker configuration LCR, Ls/Rs, Lb/Rb and
HL/HR. When PLIIz is selected, there is no output on HLs/HRs and HC/T.
These are configuration options for Dolby PLIIz mode:
Height Gain: Low, Mid, or High – This determines how much of the audio gets pushed up to the
higher speakers (measured in dB). When set to high, more sound will come from the Left High and
Right High speakers (HL/HR).
1.4.2.3 Dolby PLII
Dolby PLII is available only when the speaker configuration does not include the back surround channels
(BL/BR). It is used to expand 2-channel to fill up to 5.1 speaker configurations.
These are configuration options for Dolby PLII mode:
Dolby Pro Logic
Music
Panorama On or Off – create a seamless wraparound surround effect.
Center Width – from 0 (off) to 7 (Phantom). This controls the balance of the main vocals in the
center and front channels for more natural sound.
Dimension – adjusts the balance of the surround sound from +7 (Full to Surround) to -7 (Full to
Front).
Movie – optimized for movie presentation.
