FUEL SYSTEM - Injection Pump FU-41

21. REMOVE DELIVERY VALVE HOLDERS

(a) Using SST, remove the delivery valve holders, springs
and spring seats.
SST 09260-5401 2 (09269-54020)
(b) Remove the delivery valves and gaskets.
NOTICE: Do not touch the sliding surfaces of the
delivery valve with your hand.
HINT: Arrange the delivery valves, springs, spring seats
and holders in order.

22. REMOVE DISTRIBUTIVE HEAD

(a) Using a 5 mm hexagon wrench, remove the four bolts.
