Lenovo x3650 M5 Installation And Service Manual page 223

Cable cover
Figure 153. Cable cover removal
8. Grasp the EIA assembly and pull it slightly forward to remove it from the server.
Figure 154. EIA assembly removal
9. If you are instructed to return the EIA assembly, follow all packaging instructions, and use any packaging
materials for shipping that are supplied to you.
3.5-inch model
There are the right EIA assembly and the left EIA assembly on the server, use the following steps to remove
them.
For the right EIA assembly
1. Read the safety information that begins on "Safety" on page v and "Installation guidelines" on page 289.
2. Turn off the server and peripheral devices, and disconnect the power cord and all external cables.
3. Remove the top cover (see "Removing the top cover" on page 143).
EIA assembly
Chapter 5
.
Removing and replacing components
211
