ENGINE OIL REPLACEMENT
I
~~Jlfil
3-20
10. Install :
eAir bleed screw
Air bleed screw:
5 Nm (0.5 m-kg, 3.6 ft-Ib)
11. Inspect :
-Oil level
Refer to the "ENGINE OIL LEVEL INSPEC-
TION" section .
-Oil pressure
Refer to the " OIL PRESSURE INSPEC-
TION" section.
-Oil leaks
12. Install:
- Oil tank cap
-Cover
Engine oil replacement (with oil filter)
1.
Place the motorcycle on a level place .
2. Remove:
- Cover (fuel tank)
Refer to the "SEAT,FUEL TANK AND
COVER " section.
3 .
Warm up the engine for several minutes,
th en stop the engine. Then place a recep-
ta cle under the drain bolts.
4.
Remove:
- Oil tank cap
- Drain bolt
CD
(oil tank)
e Drain bolt
CV
(crankcase)
5.
Drain :
- Engine oil
NOTE : ________________________ __
When the drain bolt
CD
is removed, the oil will
not drain directly downward . Therefore a
receptacle should be placed slightly in front of
the drain bolt .
6 . Remove :
eAir bleed screw
CD
eBolt
CV
NOTE: ________________________
~--
The oil filter cover is secured by three screws.
The lower one should be removed so that the
filter cavity will drain.
