244
CHAPTER 4
Using the Gateway
RTU table
The lower part of the "Copy RTU" window contains the table of
the copies of the selected RTU:
Figure 276. Copy RTU - RTU table
The list of the saved RTU copies contains the following informa-
tion:
•
# - current number of the copy;
•
Name - name of the new RTU;
•
Code - unique code of the new RTU for addressing it;
•
Serial number - enter the real serial number of the new
RTU;
•
Copy routes - the routing information of the original RTU
will be copied if this check box is marked.
Note: Name, code and serial number of the copies have to be
replaced by the actual terms of the copied RTUs, in the cor-
responding fields of the copied RTUs.
Replace RTU
Figure 277. RTU Context Menu - RTU Administration - Replace RTU
"Replace" allows you to transmit information within your RTU net-
work from an existing RTU (the source RTU) to another RTU (the
destination RTU).
