CDM-700 High Speed Satellite Modem
Front Panel Operation
If Intfc1 Port1 Rx Buffer:
Intfc1 Port1 Rx Buffer:
(65%) Re-Center
The percentage (65%) indicates the current buffer fill status. Select Re-Center, using the
arrow keys, to reset the buffer to the midpoint (50%). Press
If Intfc1 Port1 Rx Buffer:
Intfc1 Port1 Rx Clk:
Rx-Sat
This selection determines which source clocks the output of the Rx Buffer for delivering data to
the Rx port at the user interface.
Select Rx-Sat, Tx-Terr or Ext-Clk using the
are as follows:
Selection
Rx-Sat (default)
Tx-Terr
Ext-Clk
If Intfc1 Port1 Rx:
Intfc1 Port1 Rx Status
Enable Disable
This selection activates or deactivates the receive side of Port1. Disabling the Rx port deactivates
the port and changes the data rate to 0.
Select Enable or Disable using the
ReCenter is selected:
Clk is selected:
Tx-Terr Ext-Clk
Description
Effectively disables the Rx Buffer because the input and output
clocks are the same. Normally, the Rx Buffer is set for minimum
when Rx-Sat is selected.
Uses the clock from the Tx input to clock out the Rx Buffer.
Derives a clock from a signal input to the Ext-Clk connector on the
E3/T3/STS-1 Interface Card.
Ena/Dis is selected:
(
◄ ►
arrow keys. Press
6–29
(E)
.
ENTER
◄ ►
arrow keys. Press
E)
ENTER
Revision 5
MN/CDM700.IOM
◄ ►
. The selections
ENTER
.
