CDM-700 High Speed Satellite Modem
Summary of Specifications
10.8 Data Interface (Optional)
Note: Additional information about the data interfaces is available in the applicable appendix.
Interface Type
CDI-10
CDI-50
CDI-60
CDI-70
10.9 Environmental and Physical
Temperature
Humidity
Power Supply Input
Power Consumption
Dimensions
Weight
Agency Approvals
Description
2 independent G.703 interfaces at 75Ω unbalanced each programmable to
E3/T3/STS-1 34.368/44.736/51.84 Mbps. Line codes are AMI (NONE), HDB3,
and B3ZS.
2 types of OC-3 / STM-1 modules area available and one is selected at the time
of order. Each module has two interfaces: one optical, the other copper (coaxial),
and the user programs the active one
1 each HSSI Port
1 each RJ-45 Port
Operating
0 to 50°C (32 to 122°F)
Storage
-25 to 85°C (-13 to 185°F)
95% maximum, non-condensing
AC
100-240 VAC (50 to 60 Hz)
DC
48 VDC
120 VAC @ 60 Hz
80W, 81.5 VA maximum
220 VAC @ 50 Hz
67W, 87 VA maximum
48 VDC
1.6A, 77W maximum
19W x 18.65D x 1.75H inches
(48W x 47.4D x 4.4D cm)
15 lbs (7.0 kg) approx
EMC
Safety
10–8
Revision 5
MN/CDM700.IOM
