CDM-700 High Speed Satellite Modem
Front Panel Operation
If the selected location does not contain a previously stored configuration, the following screen is
displayed:
New Config has been
Saved to Loc 9
However, if the selected location does contain a previously stored configuration, the following
screen is displayed:
Loc 0 Contains Data !
Overwrite? NO YES (
Select No or Yes using the ◄ ► arrow keys, then press
existing configuration at the selected location.
Save/Load Configuration:
Load Config from Loc: 9
11:02:43
Using Loc: 9 as the example, if Load is selected and there is a configuration stored at the
selected location, what displays is similar to the preceding example. Note that the stored
configuration is identified with a date and time stamp.
If the selected location contains no data, what displays is similar to the next example:
Load Config from Loc: 9
Empty
Select the location from where the current configuration is to be loaded using the
keys, then press
If the selected location contains valid data, what displays is similar to the following example:
New Config has been
Loaded from Loc #
Press
or
ENTER
If the selected location contains invalid data, what displays is similar to the next example:
Warning! Loc 9 Contains
No Data!
Press
or
ENTER
05/08/05
. Locations 1 through 10 are available.
ENTER
to return back to the previous menu.
CLEAR
to return back to the previous menu.
CLEAR
(E)
E)
ENTER
Load
(
E)
(
E)
(E)
(E)
6–65
MN/CDM700.IOM
. Selecting Yes overwrites the
arrow
Revision 5
