CDM-700 High Speed Satellite Modem
SNMP Interface
12.5.4 Modem Reference Group
This group provides the parameters for selection of the modem's frequency reference.
12.5.5 Monitor Group
This group provides access to the units current Alarm/Fault Status as well as a table to access the
Stored Alarms/Events.
12.5.6 Test Group
This group provides access to the units test modes.
12.5.7 Save/Load Group
This group provides control of the unit's configuration Store and Load capabilities.
12.5.8 Firmware Group
This group provides a table of firmware numbers, Revision Numbers, and Release Dates for all
the software/firmware within the unit.
12.5.9 System Log Group
This group provides information stored in the system log of the modem, including date and time
the event occurred.
12.6
Modulator Group
The CDM-700 Modulator Group holds all unit parameters associated with the Modulator. For
detailed OID information, refer to the actual MIB file.
12.7
Demodulator Modulator Group
The CDM-700 Demodulator Group holds all unit parameters associated with the Demodulator.
For detailed OID information, refer to the actual MIB file.
12.8
Interface Group
The CDM-700 Interface Group holds all groups associated with the various Interface boards. For
detailed OID information, refer to the actual MIB file.
12–4
Revision 5
MN/CDM700.IOM
