CDM-700 High Speed Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
IP Address IPA= 18 bytes
Gigabit GIP= 19 bytes
Interface
Management
IP Address
Unit Test TST= 1 byte
Mode
Demodulator MRF= 1 byte
Mask All
Faults
Unit Alarm MSK= 3 bytes
Mask
Description of Arguments
to Query
Command or Query.
Used to set the IP address and network prefix for the
10/100 BaseTx Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (0-31)
Example: 010.006.030.001.24
Command or Query.
Used to set the management IP address and network prefix for an
GBEI interface card, in the format:
sxxx.xxx.xxx.xxx.yy, where:
s is the slot number of interface card,
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (0-31)
Example: 1010.006.030.001.24 (set IP address on Interface slot 1 to
10.6.30.1/24 )
Command or Query.
CDM-700 Test Mode, where:
0=Normal Mode (no test)
1=IF Loopback
2=Digital Loopback
3=I/O Loopback
4=RF Loopback
5=Tx CW
6=Tx Alternating 1,0
Example: TST=3 (I/O Loopback)
Command or Query
0=Unmask All Demodulator Faults(Normal Fault Reporting).
1=Mask All Demodulator Faults(All Faults Ignored).
Example.:MRF =1;
Command or Query.
Alarm mask conditions, in form abc, where:
a=Rx AGC Alarm (0 = active, 1 = masked)
b=Eb/No Alarm (0 = active, 1 = masked)
c=BER Alarm (0 = active, 1 = masked)
Example: MSK=010
Response to
Command
IPA=
IPA?
IPA*
IPA#
GIP =
GIP?
GIP*
GIP#
TST=
TST?
TST*
TST#
MRF=
MRF?
MRF#
MSK=
MSK?
MSK*
MSK#
11–17
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
IPA? IPA=
xxx.xxx.xxx.xxx.yy
GIP?s GIP=
sxxx.xxx.xxx.xxx.yy
TST? TST=x
MRF? MRF=x
MSK? MSK=abc
