Comtech EF Data CDM-700 Installation And Operation Manual page 107

CDM-700 High Speed Satellite Modem
Front Panel Operation
The display indicates if there are any Transmit Traffic Faults. If not,
to return to the previous menu.
ENTER
If Live Alarms:
Rx Traffic:
Demod Unlocked
The display indicates if there are any Receive Traffic Faults. If not,
to return to the previous menu.
ENTER
If Live Alarms:
Unit Fault:
Card
The display indicates if there are any Unit Faults. If not,
return to the previous menu.
Receive is selected:
Rx Synth
Unit is selected:
FPGA Temp
(E)
LISTING OF PRIORITIZED FAULTS
UNIT FAULTS
1) FPGA Load Framer Card
2) +1.5V PSU Framer Card
3) +1.5V PSU Interface Card #1
4) +1.5V PSU Interface Card #2
5) +3.3V PSU Framer Card
6) +5V PSU Framer Card
7) +12V PSU Framer Card
8) -12V PSU Framer Card
9) +18V PSU Framer Card
10) FLASH Checksum Error
11) FPGA Load FEC Card #1
12) FPGA Load FEC Card #2
13) FPGA Load Interface Card #1
14) FPGA Load Interface Card #2
15) PLL Clock Framer - 192 MHz
16) PLL Clock Framer - Ext Ref
17) FPGA Temp Framer Card
18) Modem Ambient Temp
19) Modem Cooling Fans
20) Intfc1 has been removed
21) Intfc2 has been removed
22) 1:1 Switch not present
(E)
Framer
None is displayed. Press
6–53
Revision 5
MN/CDM700.IOM
None is displayed. Press
None
is displayed. Press
ENTER
to
