CDM-700 High Speed Satellite Modem
SNMP Interface
12.2 CDM-700 Management Information Base (MIB) Files
MIB files are used for SNMP remote management and consist of Object Identifiers (OIDs). Each
OID is a node that provides remote management of a particular function. A MIB file is a tree of
nodes that is unique to a particular device.
The following MIB files are associated with the CDM-700:
MIB File/Name
Fw12051-2-.mib
ComtechEFData
MIB file
Fw12635-1
CDM-700 Trap
MIB File
Fw10236-4-.mib
CDM-700 MIB file
These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring System
server.
Note: The CDM-700 SNMP agent supports both SNMPv1 and v2c.
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).
enterprises(1).comtechEFData(6247)
Module: ComtechEFData
Product ID 32(CDM 700 )
CDM-700 Traps to Support SNMP v1.2
CDM-700 OBJECTS
CDM-700 –SYSTEM OBJECTS
CDM-700 MODULATOR OBJECTS
CDM-700 DEMODULATOR OBJECTS
CDM-700 INTERFACE OBJECTS
•
E3T3STS1 INTERFACE
•
OC3 INTERFACE
•
HSSI INTERFACE
•
GIGABIT INTERFACE
CDM-700 MONITOR OBJECTS
CDM-700 REDUNDANCY OBJECTS
12–2
Description
Revision 5
MN/CDM700.IOM
