CDM-700 High Speed Satellite Modem
Remote Control
Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
Qualifier)
VLAN
SVC=
8Bytes
Configuration
VLAN Table
SVT=
1 Byte
VLAN Delete
SVD=
5Bytes
Set
SCX=
2bytes
AutoCrossover
Set Learning
SLM=
2bytes
LAN to WAN
Note: Once the Learning mode is changed, cycle power to store.
Description of Arguments
to Query
Command only.
a=Interface Slot (1 or 2)";" Deleminator
bbbb=VLAN PVID(0002 to 4094)
":" Deleminator
c VLAN ATTRIBUTE
1=NATIVE
2=TAGGED
3=UNTAGGED
4=MANAGEMENT
Notes: Create PVID if PVID does't exist and make room for it PVID entry
table.
1.
If No Room in Table returns " * "
2.
If Trying to add more than one Native or Management returns *
3.
If Trying to change the attribute of a VLAN ID which is Native
or Management with different attribute.
Query only.
Returns all VLAN ID's and attributes in the table.
a=Interface Slot (1 or 2)
Example: SVT=1;0001:0002:4
The current VLAN's in the table are PVID 1 with and attribute of NATIVE
and PVID 2 with a management attribute.
Command or Query.
a=Interface Slot (1 or 2)
bbbb=VLAN PVID(0001 to 4094)
returns * if deleting Native or Management
returns * if Vlan does not exist.
Command or Query.
a=Interface Slot (1 or 2)
b=0(Set AutoCrossover to NO)
= 1(Set AutoCrossover to YES)
Command or Query.
a=Interface Slot (1 or 2)
b=0 (Set Learning to NO)
= 1 (Set Learning to YES)
Response to
Command
SVC=
SVC#
SVC*
N/A
SVD=
SVD?
SVD#
SVD*
SCX=
SCX?
SCX#
SCX*
SLM=
SLM?
SLM#
SLM*
11–29
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
N?A
N/A
SVT?a
SVT=abbbb...bbbb
Returns all VLAN ID's in
table.
SVD?a;
SVD=abbbb...bbbb
Returns last five VLAN
Deleted.
SCX?a
SCX=ab
SLM?a
SLM=ab
