CDM-700 High Speed Satellite Modem
Remote Control
Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
Qualifier)
OC3 Global
OGC=
9 bytes
Configuration
HSSI Global
HGC=
33 bytes
Configuration
Interface Type
IFA?
N/A
And
Configuartion
in Slot 1
Interface Type
IFB?
NA
And
Configuartion
in Slot 2
Description of Arguments
to Query
Command or Query.
a=Interface Slot 1 or 2
b=Interface Mode (0 = Optical, 1 = Coax)
c=Tx Enable (0=Disabled, 1=Enabled)
d=Rx Enable (0=Disabled, 1=Enabled)
e=Rx Clock Source
f=Receive Buffer Size (in milliseconds.)
Command or Query.
a=Interface Slot (1 or 2)
b=Tx Enable (0=Disabled, 1=Enabled)
c=Tx Clock Invert (0=Non-Inverted, 1=Inverted)
d=Tx Data Invert (0=Non-Inverted, 1=Inverted)
e=Tx Clock Source (Read-only)
f=Tx Datarate (in megabits per second)
g=Rx Enable (0=Disabled, 1=Enabled)
h=Rx Clock Invert (0=Non-Inverted, 1=Inverted)
i=Rx Data Invert (0=Non-Inverted, 1=Inverted)
j=Rx Clock Source
k=Rx Datarate (in megabits per second)
l=Receive Buffer Size (in milliseconds)
Command or Query.
IFA=* Turn OFF All ports on Slot 1
Command or Query.
IFB=* Turn OFF All ports on Slot 2
Response to
Command
OGC=
OGC?
OGC#
*TIE
OGC*
*RIE
*RCK
*RBS
HGC=
HGC?
*TIE
HGC#
HGC*
*TDI
*TCK
*ITR
*RIE
*RDI
*RCK
*IRR
*RBS
IFA=
IFB=
11–26
Revision 5
MN/CDM700.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
OGC?a
OGC=abcdeff.f
HGC?a
HGC=abcdefff.ffffffghijk
kk.kkkkkkll.l
IFA?
BGC =DGC port 1,DGC
port 2 for Slot1
HGC=HGC for Slot 1
GGC=GGC for Slot 1
OGC=OGC for Slot1
IFA=*(No Card Installed)
IFB?
BGC =DGC port 1,DGC
port 2 for Slot2
HGC=HGC for Slot 2
GGC=GGC for Slot 2
OGC=OGC for Slot2
IFB=*(No Card Installed)
