CDM-700 High Speed Satellite Modem
Front Panel Operation
6.3.1.1

(CONFIG:) Remote

Remote Control:
Local
Select Local, Serial or Ethernet by using the ◄ ► arrow keys, then press
Selection
Local
Serial
Ethernet
Remote Control:
When Local is selected, remote control is disabled and local control enabled
once ENTER is pressed; the CONFIG: menu returns. When Remote is selected,
menu operations associated with local control are disabled, and the following
IMPORTANT
message appears when menu or command access associated with Local
control is attempted:
Remote Control:
Serial Config: Interface
(
Select Interface or Baudrate using the ◄ ► arrow keys, then press
If Serial Config:
M&C Bus Interface: RS232
RS485-2W
Select RS232 or RS485-2W (2-wire) or RS485-4W (4-wire) using the ◄ ► arrow keys, then
press .
ENTER
Note: At this point, a prompt requests entry of the bus address.
Serial Ethernet
Action
Remote control is disabled. Remote monitoring is still possible.
RS232, RS485-2W, and RS485-4W menus are accessed.
Additional submenus will be displayed.
Local
THIS UNIT IS CURRENTLY
IN REMOTE MODE!!
Serial
E)
Interface is selected:
RS485-4W
Baudrate
( E)
6–8
Revision 5
MN/CDM700.IOM
.
