CDM-700 High Speed Satellite Modem
Front Panel Operation
The available FAST options are shown in the following table:
Option Option
Number Type
01 Hardware
02 Hardware
03 Hardware
04 Hardware
05 Hardware
06 Hardware
07 FAST
08 FAST
09 FAST
10 FAST
11 FAST
12 FAST
13 FAST
14 FAST
15 FAST
16 FAST
17 FAST
18 FAST
19 FAST
20 FAST
21 FAST
22 FAST
23 FAST
24 FAST
25 FAST
26 FAST
DATA RATE RANGE NOTES:
1. The composite data rate range depends on the FAST option ordered with
the CDM-700. The options are arranged in ascending tiers by symbol rate and
IMPORTANT
modulation type along with the corresponding data rate range.
2. The Data Rate Range Table in the Chapter 10. Summary of Specifications
summarizes the composite data range by tiers. It also shows how the
composite data rate is constructed from the individual data ports on the data
interface modules.
3. The data rate of each individual data port depends on the particular CDI-xx
data interface installed in the CDM-700. Additional information about the data
rate range for each individual port is provided in the menus below and in the
chapter for each data interface module.
Displayed
Description
Code
Mod CCA Modulator Board Installed
Demod CCA Demodulator Board Installed
TURB FEC1 Turbo FEC board installed in Slot#1
Fec Slot2 Unistalled (Slot not available)
Intfc #1 Installed or Uninstalled in Slot #1
Intfc #2 Installed or Uninstalled in Slot #2
Tx QPSK QPSK Enabled or Disabled
Tx 8PSK 8PSK Enabled or Disabled
Tx 16-QAM 16-QAM Enabled or Disabled
Tx 64-QAM 64-QAM Enabled or Disabled
Rx QPSK QPSK Enabled or Disabled
Rx 8PSK 8-PSK Enabled or Disabled
Rx 16-QAM 16-QAM Enabled or Disabled
Rx 64-QAM 64-QAM Enabled or Disabled
Tx < 15.0 MS Operation to 15.0 MS Enabled or Disabled
Tx < 22.5 MS Operation to 22.5 MS Enabled or Disabled
Tx < 30.0 MS Operation to 30.0 MS Enabled or Disabled
Tx < 37.5 MS Operation to 37.5 MS Enabled or Disabled
Tx < 45.0 MS Operation to 45.0 MS Enabled or Disabled
Tx Full Rate Full Data Rate Enabled or Disabled
Rx < 15.0 MS Operation to 15.0 MS Enabled or Disabled
Rx < 22.5 MS Operation to 22.5 MS Enabled or Disabled
Rx < 30.0 MS Operation to 30.0 MS Enabled or Disabled
Rx < 37.5 MS Operation to 37.5 MS Enabled or Disabled
Rx < 45.0 MS Operation to 45.0 MS Enabled or Disabled
Rx Full Rate Full Data Rate Enabled or Disabled
