Maintaining the printer
7
8
9
10 Replace the print ribbon cartridge.
11 Close the swing arm, pressing it down until the push latch clicks into place.
12 Close the cover by lifting it slightly, move the support up so it is parallel with the

Using the magnetic stripe cleaning card

The printer's magnetic stripe module should be cleaned when the printer has
displayed several magnetic stripe errors that list running the magnetic stripe cleaning
card as a solution. See
ordering magnetic stripe cleaning cards.
!
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Slide a new replaceable cleaning sleeve onto the spindle (step 1 in
1
Figure 4-5: Replace the cleaning roller sleeve
Hold the replaceable cleaning roller spindle by the ends and remove the
protective cover from the sleeve (step 2 in
cover.
i
Avoid touching the sticky surface of the replaceable sleeve. Oils from your
fingers could reduce cleaning and could affect card quality.
Continue to hold the spindle by the ends. Replace the spindle with sleeve in the
printer (step 3 in Figure
hinges, and lower the cover.
i
If the printer has a locking cover, lock the cover after closing it.
"Supplies and cards" on page B-1
Do not use the magnetic stripe cleaning card more than once every 2000 cards or
excessive wear can result.
2
3
3
Figure
4-5).
Figure
4-5). Discard the protective
for information about
4-5
4-5).
