Troubleshooting
Check the following:
•
•
Track
Track 1
Track 2
Track 3
Track 3
See
stripe tracks.
•
•
•
•
If you are not satisfied with the appearance of the test card, see
appearance" on page 5-8

Windows test page

Follow these steps to print a Windows test page on all supported operating systems.
Print the Windows test page
i
1
2
3
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Your service provider might ask you to use a different procedure to make a
printer test card. The card printed might have additional areas printed on it.
For UltraGrafix printers, the test card is printed with one color, such as black.
The test card has the pattern shown on the front of the card. The back of the card
will be printed with a similar pattern if the printer includes a duplex module.
If a magnetic stripe module is installed in the printer and enabled, the following
data is encoded on the card:
Format Data
(IATA) TEST PATTERN IATA CHARACTER
SUBSET 0123456789
(ABA) 012345678012345678990123456789
(TTS) 0123456789=9876543210
(NTT) 0123456789=9876543210
"Magnetic stripe encoding" on page D-1
The tracks available depend on the type of module installed.
The magnetic stripe data on the printer test card is generated by the printer and
does not test driver-to-printer communication.
If a topcoat module is installed in the printer and enabled, topcoat is applied to the
front of the card.
If an overlay module is installed in the printer and enabled, an overlay patch is
applied to the front of the card.
to identify the problem and possible solutions.
The printer must be connected to the PC with the driver installed, and both printer
and PC must be running.
Select Start from the Windows taskbar.
Select Settings and then Printers (Printers and Faxes on Windows XP) from the
Windows Start menu. The Printers (and Faxes) window appears.
Click once on the printer icon.
for more information about magnetic
"Problems with card
5-5
