Install the printer
Connect the power cord
1
2
i
3

Preparing the printer for driver installation

After connecting the printer and PC and before installing the driver, do the following:
•
•
•
•
•
•
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Attach the power cord to the power receptacle on the back of the printer (step 1 in
Figure 7-9).
Figure 7-9: Connect the power cord
Plug the other end of the power cord into a single-phase, 3-wire grounded
receptacle with 90-130V AC or 195-254V AC at 50 or 60 Hz (step 2 in
The printer power supply automatically adjusts to the voltage of the input power.
Do not power on the printer until supplies are loaded.
Load cards in the card cartridge. See
Install the continuous cleaning roller in the printer. See
roller sleeve" on page 4-3. There is no used sleeve to remove.
Install the print ribbon. See
a new printer, there is no used ribbon to remove.
If the printer includes an optional topcoat or overlay module, install the supply
material. See "Using the printer" on page
Power on the printer and PC. See
The topcoat or overlay (laminator) module must warm up before printing a card. If
you complete driver installation and print the sample card before the laminator is
ready, a message box appears asking you to wait while the laminator warms up.
The card will complete processing as soon as all modules in the printer are ready.
1
"Loading cards" on page
"Loading the print ribbon" on page
2-1.
"Powering on the printer and PC" on page
2
Figure
2-3.
"Replacing the cleaning
2-5. When installing
2-13.
7-9
7-9).
