DataCard ImageCard Magna User Manual page 49

Using the printer driver
5
6
7
Use the Default Document Properties dialog box
Make sure the printer power is on and the printer is connected to the PC.
1
2
3
4
5
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Select the tab that contains the information you want to view or change.
If you make changes, click OK to save the settings and close the dialog box. If you
do not want to make changes, click Cancel to close the Properties dialog box.
If you change the port, restart Windows and power cycle the printer.
Select Start from the Windows NT taskbar.
From the Windows NT Start menu, select Settings and then Printers. The Printers
window appears.
Click once on the SmartDriver icon.
Select File from the Printers menu bar, and then select Document Defaults. The
SmartDriver Default Document Properties dialog box appears.
Figure 3-6: Default Document Properties dialog box, Windows NT
Select the tab that contains the information you want to view or change. On the
Advanced tab, click the plus sign (+) if needed to see all selections available.
When you click a selection, choices appear in the "Change. . . " box. Click the
value you want.
If the selections you want to use are not available (are grayed out), make sure the
feature is available in the printer. Also make sure that the printer is powered on
and connected to the PC and resume the Status Monitor. See
3-9
"Opening and using
