Maintaining the printer
6
7
8
9
10 Power on the printer.
11 Print a card to verify the quality of printing. You can print a sample card or a card
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
i
The notches on the printhead cartridge should align with the notches on the
spring bar (A in
Figure
Figure 4-20: Secure the printhead cartridge
Hold the printhead cartridge latch lever down (step 1 in
printhead cartridge down toward the swing arm (step 2 in
the latch lever when the printhead cartridge is in place.
Clean the printhead. Move the cleaning pen back and forth along the length of the
printhead edge. (See
Figure 4-15 on page
rounded edge of the printhead.
Close the swing arm, pressing it down until the push latch clicks into place.
To close the cover, lift the top slightly. Move the support up so it is parallel with the
hinges and lower the cover.
i
If the printer has a locking cover, lock the cover after closing it.
using your card creation application. If card quality is still inadequate, see
"Troubleshooting" on page
4-20).
A
2
1
4-15.) Be sure to completely clean the
5-1.
4-19
Figure
4-20) and pivot the
Figure
4-20). Release
