Cleaning The Printer Rollers - DataCard ImageCard Magna User Manual

4-6
Run the magnetic stripe cleaning card
1
2
3
4

Cleaning the printer rollers

The printer rollers move the card during printing or cleaning operations. Clean the
rollers once a week or when problems occur such as repeated card jams or cards not
being picked.
Clean printer rollers
1
Insert a magnetic stripe cleaning card into the exception card slot. Make sure the
arrow is on top and pointing into the printer (see
remove the card cartridge and place the cleaning card on the card input rollers.)
Figure 4-6: Insert the magnetic stripe cleaning card
!
Do not peel off the blue stripe on the back of the card.
Open the Status Monitor by double-clicking the icon.
Click the Mag Stripe button in the Clean area.
The printer automatically runs the magnetic stripe cleaning process and ejects the
card in the output stacker when it is complete.
Remove the used magnetic stripe cleaning card. The card can be used again.
Open the Status Monitor by double-clicking the printer icon.
i
Make sure that printing of cards is complete before cleaning the rollers.
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Maintaining the printer
Figure 4-6). (You can also
