2-8

Removing the supply cartridge

Remove the supply cartridge when a "Supply empty" message appears, or when
setting up the printer.
Remove the supply cartridge
1
2
3
4

Loading supply in the cartridge

After removing the supply cartridge from the printer, remove the used material and
load new material.
If the printer has a locking cover, unlock the cover before opening it.
Lift the top cover, and then move the support down so it rests on the internal
frame, as shown in Figure
!
The module is HOT to the touch and remains HOT for up to 30 minutes after
the printer is powered off.
Lift the supply tracker, and then push until it clicks into place (step 1 in
Figure 2-10).
Figure 2-10: Remove the supply cartridge
Pull out on the cartridge lock to release the supply cartridge (step 2 in
Figure 2-10).
Pull the supply cartridge out until the cartridge is out of the printer (step 3 in
Figure 2-10).
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
2-5.
Supply tracker
Using the printer
2
3
