Overview
Topcoat supply cartridge (optional)
This cartridge holds the topcoat supply and can be removed for easy reloading.
Laminator advance knob (optional)
The laminator advance knob turns to move a card along the card transport track in the
topcoat or overlay module. Use it to release stuck cards in the topcoat or overlay
module.
Debower (optional)
The debower is part of the optional laminator module and corrects for any change to
the flatness of the card caused by heat applied by the laminator module.
Supply tracker (optional)
The supply tracker is part of the optional laminator module and measures the
movement of the supply material as it moves from the supply spool.
Printhead cartridge
The printhead, contained in the printhead cartridge, applies heat and pressure, which
transfers dye and other material from the print ribbon to the card. The printhead
cartridge is replaceable.
Printer label
The printer label includes the printer serial number and information about optional
components of the printer.
Print ribbon cartridge
The print ribbon cartridge holds the print ribbon.
Card advance knob
The card advance knob turns to move a card along the card transport track. If a card
remains in the printer, use this knob to move the card in the card track.
Continuous cleaning roller
The continuous cleaning roller is a new feature of the Magna Class printer with
Advanced Imaging Technology. The roller includes a spindle and a replaceable
cleaning sleeve. The spindle holds the roller in place. The replaceable cleaning sleeve
removes dirt and debris from the permanent cleaning roller in the printer and should
be changed regularly.
