DataCard ImageCard Magna User Manual page 30

2-12
2
3
Pull out the handle for the debower and move it to the desired position for the card
type. Figure 2-13 shows the on and off positions for the debower.
Card or module type
0.030 inch (0.76 mm) card
0.050 (1.27 mm) cards
Smart card
Proximity card
Topcoat module
If you use a topcoat or overlay module, you must use cards that are at least
0.030 inch or 0.760 mm thick.
Make sure the debower is seated in the latch.
Figure 2-13: Lift the handle, move the debower, and lower it
To close the cover, lift the top slightly. Move the support up so it is parallel with the
hinges.
If the printer has a locking cover, lock the cover after closing it.
If you are setting up the printer, check the bow on the test card when you make it.
If you are changing this settings after running the printer with other cards, make
several test or sample cards to be sure the setting produces the result you want.
If you are switching to proximity cards or use smart cards, be sure to test the
function of the card after applying the overlay or topcoat.
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
Debower position
on
off
off
off
off
On
Using the printer
Off
