5
4
-
Figure 5-1: Press and hold Ready button (1) and then Press Power switch (2)
4
i
5
Printer test card
The printer test card is designed to perform most functions available in the printer.
Release the Ready button. You hear the internal components initialize. Allow 30
to 60 seconds for the printer to begin printing the test card. The status light will
flash green while the printer is processing the data.
If the printer includes a topcoat or overlay module, the module might require time
to heat up. The card pauses and the module makes a series of beeps while it is
warming up.
Remove the card from the card output stacker. A printer test card is shown in
Figure
5-2.
If the printer test card did not print successfully, see
needed, turn to
"Troubleshooting" on page
Red
Green
Dark Blue
Black
Figure 5-2: ImageCard printer test card (using color ribbon)
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
2
1
5-1.
Blue Cyan
Magenta
Yellow
Black
Black Border
Troubleshooting
"Status light" on page
2-15. If
