DataCard ImageCard Magna User Manual page 64

4-10
2
3
4
5
6
7
Peel the middle strip of protective paper from both sides of the duplex/laminator
cleaning card (see Figure
i
The outside protective paper strips must stay on the card.
Figure 4-9: Duplex/laminator cleaning card
Insert the duplex/laminator cleaning card near the bottom of the card cartridge
cavity (see Figure 4-10).
Figure 4-10: Insert the duplex/laminator cleaning card
Open the Status dialog box by double-clicking the icon.
Click the Duplex/Laminator button in the Clean area.
The printer automatically runs the laminator cleaning process and ejects the card
in the output stacker when it is complete.
Remove the used cleaning card and discard it.
Replace the card cartridge. Push the bottom of the card cartridge until it clicks into
place.
i
If the printer has a locking card cartridge, lock the cartridge after replacing it.
The duplex and laminator modules are clean and the printer is ready to resume
normal operation.
User's Guide for ImageCard® Magna™ and UltraGrafix® Magna™ Printers
4-9).
Maintaining the printer
Keep
Remove
Keep
