User Manual: WaveLinx Lite (4.0)
View Status and Device Details in a Standalone Area
To access the device details pages:
1: Ensure that the mobile device Bluetooth is turned on, and then open the WaveLinx Lite Mobile Application.
2: In the site list, select a site and then in the area list, select the standalone area.
3: Bring the mobile device within range (within 60 feet) of the desired device and then select the device from the 'Devices in this Area' section to
open the device details.
Select the site
Device Details Dimmable Page
Select the area
Setting
Default
Level
N/A
Adjustment
Actual Level
N/A
Blink to Identify
N/A
Location
N/A
Trim Settings
Min 0%
Max 90%
Select a device
Description
Displays the current light level of the dimmable device. Use the
slider or entry field to temporarily issue a high priority override
to the light level. Light level will revert to normal operation after
10 minutes if still in the device details page at this time or once
the screen is exited.
Note: Light level may not automatically refresh if commands have
processed after screen was entered.
Displays the current light level of the dimmable device.
Note: Light level may not automatically refresh if commands have
processed after screen was entered.
Tap on the icon '
' to cause the connected fixture to flash on
and off for a 15 second period. To cancel 'blink to identify'
before the timer expires, tap '
Lists the site, area, and zone that the device is assigned to.
Displays the current trim settings for the device.
• The minimum level is the lowest level that dimming
commands can set the dimmable light level to (low end
trim). Regardless of the minimum level set, a 0%
command will turn the load OFF.
• The maximum level sets the highest level that a dimming
command can set the dimmable light level to (high end
trim).
The fields can be used to modify the settings. Tap 'Save' after
modifying the trim settings.
' again.
www.cooperlighting.com
143
