ICP-CC408 | Installation Guide | 15.0
15.4
Zone Status – Alarm Restore Code
Location
331
14
Default
If Zone Alarm Restore Reports are required,
program this location as 14. If not, program this
location as 0.
Location 332 (Section 15.5 Zone Status Reporting Options
on page 65) is ignored when programming the Alarm
Restore code and is global for all zones. A zone
Restore Report is sent only to the receiving party to
which the zone is allocated (for example, Receiver 1
or Receiver 2).
15.5
Zone Status Reporting Options
Location
332
0
No zone status reports allowed
1
Report to Receiver 1
2
Report to Receiver 2
4
Report to both Receiver 1 and Receiver 2
8
Report to Receiver 2 only if Receiver 1 fails
This location is set by default to report only to
Receiver 1. You can select whether Zone Status
Reports are sent to Receiver 1, Receiver 2, or both,
Receiver 2 only when Receiver 1 fails, or there is no
reporting at all.
For a partitioned ICP-CC408 Control Panel, this
location is ignored if Option 1 is selected in Location
433 (refer to Section 19.3.2 Partitioning Options 2 on
page 83).
15.6
Open/Close Reports
333 to 334
Location
Open Report
Close Report
An Opening Report (Contact ID Event Code 401) is
sent to the base station receiver when the system is
disarmed from AWAY Mode. A Closing Report
(Contact ID Event Code 401) is sent at the end of
Exit Time when the system is armed in AWAY
Mode.
If an expanded format is selected, this code is used as
the Expansion Code and the user number that armed
or disarmed the system follows in the same
transmission.
To enable Open and Close Reports in STAY Mode,
select Option 2 in Location 178 (refer to Section 12.2
Dialer Options 2 on page 53). To enable Open and
Close Reports only after a previous alarm, select
Option 1 in Location 178.
If Open and Close Reports are not
required, program Locations 333 and 334
as 0.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Reporting Information
15.7
Location
0
1
2
4
8
This location is set by default to report only to
Receiver 1. You can select whether Open and Close
Reports are sent to Receiver 1, Receiver 2, or both,
Receiver 2 only when Receiver 1 fails, or there is no
reporting at all.
15.8
Location
Default
A Duress Report (Contact ID Event Code 121) is
sent to the base station receiver when 9 is added to
the end of any valid User Code used to disarm the
system. This alarm is always silent. A Duress Alarm
can be activated during Exit Time (in other words, if
the system is armed and then disarmed by adding 9
to the end of the User Code before Exit Time
expires, a Duress Report is transmitted). Adding 9 to
the end of a User Code when arming the system does
not cause a Duress Alarm.
If you want a 3 to activate a Codepad Duress Alarm
instead of 9, select Option 2 in Location 430 (refer to
Section 18.7 Consumer Options 3 on page 81).
Location
Default
333
11
334
12
15.9
Location
Tens digit
Units digit
A Panic Alarm Report (Contact ID Event Code 120)
is sent to the base station receiver when a user
presses either [1] and [3] or [STAY] and [AWAY] at
the same time. A Panic Alarm is audible, but you can
program the alarm as silent by selecting Option 1 in
Location 425 (refer to Section 18.2 System Options 2 on
page 79).
Open/Close Reporting Options
335
No Open/Close Reports allowed
Report to Receiver 1
Report to Receiver 2
Report to both Receiver 1 and Receiver 2
Report to Receiver 2 only if Receiver 1 fails
Codepad Duress Report
336
6
Restore Reports are not sent for this
event.
If Duress Reports are not required,
program Location 336 as 0.
Codepad Panic Report
337 to 338
Restore Reports are not sent for this
event.
If Panic Reports are not required, program
Locations 337 and 338 as 0.
EN | 65
Location
Default
337
7
338
15
