ICP-CC408 | Installation Guide | 4.0
AREA DISPLAY Indicators
The group of four AREA DISPLAY indicators shows
the area to which the eight zones belong. For
example, if the Area 1 indicator is lit, the ZONE
indicators correspond to the zones assigned to that
area.
Press [AWAY] to move to the next area display. For
example, if the Area 1 indicator is lit, pressing
[AWAY] extinguishes the Area 1 indicator and lights
the Area 2 indicator.
Table 15: AREA DISPLAY Indicators
Indicator
Definition
On
Information is shown for the area.
Off
Information is not shown for the area.
AUX Indicator
If Options 8 is selected in Location 432 (refer to
Section 19.3.1 Partitioning Options 1 on page 82), the
AUX indicator lights when the control panel is using
the telephone line. The AUX indicator also flashes
with the PARTIAL indicator when Installer's
Programming Mode or Master Code functions are
used.
Table 16: AUX Indicator
Indicator
Definition
On
The control panel is using the
telephone line.
Off
The control panel is not using the
telephone line.
Flashing
Installer's Programming Mode or a
Master Code function is active.
MAINS Indicator
The MAINS indicator shows the status of the AC
MAINS supply (refer to Table 11 on page 16).
When programming in Installer's Programming
Mode or using a Master Code function, the MAINS
indicator lights to indicate a location value from 10 to
15. The MAINS indicator represents the 10 digit,
which is added to the value of the lit zone indicator
(for example, if the value programmed in a location
is 12, the MAINS and Zone 2 indicators light).
FAULT Indicator
The FAULT indicator lights when the system detects
a system fault (refer to Table 12 on page 17). Refer to
Section 4.12 Fault Analysis Mode on page 23 for more
information on system faults.
Each time a new system fault is detected (the FAULT
indicator flashes), the codepad beeps once per min.
Press [AWAY] to stop the beeping and to
acknowledge the fault.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Operations
PARTIAL Indicator
The PARTIAL indicator shows when the system is
armed in STAY Mode 1. The PARTIAL indicator
flashes with the AUX indicator when Installer's
Programming Mode or a Master Code function is
active. Refer to Table 17 on page 19.
Table 17: PARTIAL Indicator
Indicator
On
Off
Audible Indicators
The codepad provides a number of audible
indications. Refer to Table 13 on page 17.
4.0 System Operations
This section explains the general operations of the
system: arming and disarming the system in the three
modes: isolating zones, initiating codepad alarms,
and determining a fault.
4.1
Arming the System in AWAY Mode
Arming the system in AWAY Mode is normally
performed when you leave the premises and require
that all zones are activated in a ready state to detect
an intrusion.
There are two different methods to arm the system in
AWAY Mode. You can always use method one.
You can use method two only if Option 2 is enabled
in Location 429 (refer to Section 18.6 Consumer
Options 2 on page 81).
If you must isolate a zone or zones prior to arming
the system in AWAY Mode, refer to Section 4.11
Isolating Zones on page 23.
Single button arming in AWAY Mode
reports as User Code number 16.
To arm the system in AWAY Mode (method one):
Enter your code and press [AWAY].
Two beeps sound, the AWAY indicator lights, and
Exit Time starts.
To arm the system in AWAY Mode (method two):
Select Option 2 in Location 429 to
enable single button arming in AWAY
Mode (refer to Section 18.6 Consumer
Options 2 on page 81).
1. Press and hold [AWAY].
2. When two beeps sound, release the button.
The AWAY indicator lights and Exit Time starts.
Definition
The system is armed in STAY Mode 1.
The system is not armed in STAY Mode 1.
EN | 19
