ICP-CC408 | Installation Guide | 4.0
To enter Fault Analysis Mode to determine a
system fault other than the AC MAINS supply:
1. Press and hold [5] until two beeps sound.
The FAULT indicator remains lit and the STAY
and AWAY indicators flash.
The lit zone indicators indicate the type of fault
that occurred. Refer to Table 18.
2. To exit from Fault Analysis Mode, press
[AWAY].
The STAY and AWAY indicators are
extinguished and the FAULT indicator remains
lit.
Table 18: Fault Indicators
Zone
Indicator
Fault Description
1
Low battery
2
Date and time
3
Sensor watch
4
Horn speaker disconnected
5
Telephone line fault
6
EEPROM Fail
7
AUX Power Supply Fail
8
Communications failure
4.13
Fault Descriptions
1 – Low Battery
A low battery fault is registered when the battery
supply voltage falls below 11.2 VDC or when a
Dynamic Battery Test detects a low capacity battery.
This fault clears after a successful Dynamic Battery
Test. The system performs a Dynamic Battery Test
every 4 hours after power is connected to the control
panel and every time the system is armed.
When reporting to the base station receiver, the
control panel sends a Battery Test Failure Report
(Contact ID Event Code 309) to indicate the low
battery fault.
2 – Date and Time
The date and time fault is registered every time the
control panel is powered down. This type of fault
causes the FAULT indicator to flash only if the Auto
Arming Time is programmed in Locations 414 to 417
(refer to Section 17.12 Auto Arming Time on page 77). If
this timer is not programmed, a date and time fault is
indicated only when you enter Fault Analysis Mode.
This fault clears after you program the date and time.
Refer to Section 6.2.8 Setting the Date and Time on page
38 for more information.
3 – Sensor Watch
A sensor watch fault is registered when one of the
detection devices stops working or fails to detect
movement during the programmed time period when
the system is disarmed. The sensor watch fault clears
after the registered zone is unsealed and resealed.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Operations
To determine the zone that registered the sensor
watch fault:
1. In Fault Analysis Mode, press and hold [5].
The indicator for the faulted zone is lit.
2. Release the button.
Program the Sensor Watch Time in Locations 408
and 409 (refer to Section 17.7 Sensor Watch Time on
page 76). To select the zones to be monitored for
sensor watch, refer to Section 14.3.5 Zone Options 1 on
page 60.
When reporting to the base station receiver, the
control panel sends a Self Test Fail Report (Contact
ID Event Code 307) to indicate the sensor watch
fault.
4 – Horn Speaker Monitor
A horn speaker monitor fault is registered when the
horn speaker is disconnected from the control panel.
This fault clears when the horn speaker is
reconnected. To enable monitoring of the horn
speaker, select Option 2 in Location 424 (refer to
Section 18.1 System Options 1 on page 78).
5 – Telephone Line Fault
A telephone line fault is registered when the
telephone line is disconnected from the control panel
longer than 40 sec. This fault can occur only only if
Option 1 is selected in Location 176 (refer to Section
11.11 Telephone Line Fault Options on page 49). The
fault clears when the telephone line is reconnected
longer than 40 sec.
6 – EEPROM Fail
An EEPROM fail is registered when the control
panel detects an internal checksum error. You must
power down and default the control panel to clear
this fault.
7 –
AUX Power Supply
This fault occurs when either the 1 A, 12 V
accessories AUX power supply or the 1 A codepad
AUX power supply fails. Ten sec after the AUX
power supply fails, the control panel automatically
sends a System Trouble code (Contact ID Event
Code 300) to the base station receiver. Ten sec after
the PTC is reset, the control panel sends a Trouble
Restore Report.
If both 1 A AUX power supplies fail, only
one system Trouble Report is sent to the
base station receiver. The Trouble
Restore Report is sent only after both
AUX power supplies are reset.
8 – Communication Failure
A communication failure fault is registered if calls to
the primary and secondary telephone numbers for
Receiver 1 or Receiver 2 are unsuccessful.
Fail
