ICP-CC408 | Installation Guide | 10.0
3. Enter [9 6 0] and press [AWAY] to exit from
Installer's Programming Mode.
Two beeps sound and the STAY and AWAY
indicators are extinguished. The system returns
to the disarmed state.
4. To program your telephone numbers, enter your
Master Code and press [2][AWAY].
Three beeps sound and the STAY and AWAY
indicators flash.
If telephone numbers are already programmed,
they appear one digit at a time using the codepad
indicators.
If no telephone numbers are programmed, an
additional two beeps sound after entering this
mode. These two beeps normally sound after the
last digit of the last phone number is displayed.
5. Enter the digits for telephone number 1, one
digit at a time.
As you enter each digit, the corresponding
codepad indicator lights.
6. After you enter all the digits of the first telephone
number, press [STAY][4] to insert a break
between the first telephone number and the
second telephone number.
7. Repeat Step 6 for each additional phone number.
8. After the last digit of the last telephone number,
press [AWAY] to exit from this mode.
Table 41: Domestic Dialing Digits
Digit
Number to
Required
Program
0
0
1
1
2
2
3
3
4
4
5
5
6
6
Example
To program two separate telephone numbers (9672
1777 and 9672 1233), enter the following sequence:
[2 5 8 0 2][AWAY][9 6 7 2 1 7 7 7][STAY] [4 9 6 7 2
1 2 3 3][AWAY]
You can cancel domestic dialing at any time (for
example, you are moving house and do not want the
system to continue calling your work place or mobile
phone).
To disable domestic dialing:
Enter your Master Code and press
[2][AWAY][STAY][4][AWAY].
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Dialer Reporting Formats
Digit
Number to
Required
Program
7
7
8
8
9
9
*
* 1
#
* 2
4 sec pause
* 3
break
* 4
10.0 Dialer Reporting Formats
10.1
Transmission Formats
The ICP-CC408 Control Panel provides a number of
transmission formats for its dialing and
communication features. Program the transmission
format for Receiver 1 in Location 033 and the
transmission format for Receiver 2 in Location 073
(refer to Section 11.4 Transmission Format for Receiver 1
and Receiver 2 on page 50). The control panel is set at
the factory to report in the Contact ID Format.
10.1.1
Contact ID Format
Contact ID Format can identify hundreds of
protection zones by their unique codes. This format
provides a single-digit Event Qualifier and a three-
digit Event Code that quickly identifies the reported
condition.
In general, Contact ID Format is very simple because
most of the Event Codes and Point ID Codes are
predefined. The base station software usually can
identify an alarmed zone by its Point ID Code and
usually pays little attention to the Event Code.
Refer to Section 10.1.2 Point ID Codes for more
information about the ICP-CC408 Point ID Codes.
10.1.2
Point ID Codes
Table 46 on page 47 shows the different Point ID
Codes and Event Codes that are transmitted to the
base station receiver when using Contact ID
Reporting Format. All Event Codes are fixed. The
control panel always transmits the same code
because there are no programming locations to
change the codes.
10.1.3
4 + 2 Reporting Format
The 4 + 2 Express Format reports a Subscriber ID
Number followed by an Expansion Code. The
reporting Channel Number is transmitted directly
after the Expansion Code.
Table 42: Example Reporting in 4 + 2 Format
Subscriber ID
Expansion
Number
Code
SSSS
A
EN | 44
Channel
Number
C
H
