ICP-CC408 | Installation Guide | 24.0
Zone Pulse Count Settings
Program the pulse count settings for each zone from
0 to 15.
Zone Pulse Count Time
Zone pulse count time is the time frame or period
over which the number of pulses must register.
20 ms Loop Response
Option Time (sec)
0 0.5
1 1
2 2
3 3
4 4
5 5
6 10
7 15
Zone Options 1
Option Description
1 Lockout siren/lockout dialer
2 Delay alarm reporting
4 Silent alarm
8 Sensor watch
Zone Options 2
Option Description
1 Isolated in STAY Mode 1
2 Zone isolation allowed
4 Forced arming allowed
8 Enable Zone Restore Report
Zone Dialer Options
Option Description
0 No report required
1 Receiver 1
2 Receiver 2
4 Receiver 1 and 2
8 Receiver 2 only when Receiver 1 fails
Zone Descriptions
Use this table as a reference to indicate what each
zone is connected to.
Zone Description
1
2
3
4
5
6
7
8
Swinger Shutdown Count for Siren
323
Location
Default
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Programming Sheets
150 ms Loop Response
Option Time (sec)
8 20
9 30
10 40
11 50
12 60
13 90
14 120
15 200
Refer to page 63
3
Swinger Shutdown Count for Dialer
324
Location
Default
Zone Status – Bypass Reports
325 to 326
Location
Default
Location 325 Zone Bypass Report
Location 326 Zone Bypass Restore Report
Zone Status – Trouble Reports
Location 327 to 328
Default
Location 327 Zone Trouble Report
Location 328 Zone Trouble Restore Report
Zone Status – Sensor Watch Reports
329 to 330
Location
Default
Location 329 Sensor Watch Report
Location 330 Sensor Watch Restore Report
Zone Status – Alarm Restore Code
Location 331
Default
Zone Status Reporting Options
Location 332
0 No report required
1 Receiver 1
2 Receiver 2
4 Receiver 1 and 2
8 Receiver 2 only when Receiver 1 fails
Open/Close Reports
Location 333 to 334
Default
Location 333 Opening Report
Location 334 Closing Report
Open/Close Reporting Options
335
Location
0 No report required
1 Receiver 1
2 Receiver 2
4 Receiver 1 and 2
8 Receiver 2 only when Receiver 1 fails
Codepad Duress Report
Location 336
Default
Codepad Panic Report
Location 337 to 338
Default
Codepad Fire Report
Location 339 to 340
Default
EN | 101
Refer to page 63
6
Refer to page 64
9 8
Refer to page 64
2 3
Refer to page 64
4 5
Refer to page 65
14
Refer to page 65
Refer to page 65
11 12
Refer to page 65
Refer to page 65
6
Refer to page 65
7 15
Refer to page 66
7 14
