ICP-CC408 | Installation Guide | 11.0
11.2
Secondary Telephone Number for
Receiver 1 and Receiver 2
016 to 031 (Receiver 1)
Location
0
Default
Location
056 to 071 (Receiver 2)
Default
0
Refer to Section 11.1 Primary Telephone Number for
Receiver 1 and Receiver 2 on page 49 for programming
information.
When Receiver 1 or 2 is set up for
domestic reporting, telephone numbers
programmed into these locations are
ignored. Refer to Section 6.1.2 Changing
Domestic Phone Numbers on page 29
(using the Installer Code function) or
Section 6.2.4 Changing Domestic Phone
Numbers on page 35 (using the Master
Code Function).
11.3
Handshake Tone for Receiver 1 and

Receiver 2

032 (Receiver 1)
Location
1
HI LO handshake (Contact ID)
2
1400 Hz (Ademco TX at 1900 Hz)
3
2300 Hz (Low Speed Sescoa)
4
No handshake
5
Pager
072 (Receiver 2)
Location
1
HI LO handshake (Contact ID)
2
1400 Hz (Ademco TX at 1900 Hz)
3
2300 Hz (Low Speed Sescoa)
4
No handshake
5
Pager
These locations set the type of handshake tone
required for the receivers before data transmissions
to the monitoring station begin.
1 – HI LO Handshake
HI LO Handshake Tone is required to communicate
in Contact ID Format or High Speed DTMF.
2 – 1400 Hz
1400 Hz Handshake Tone is required to
communicate in Ademco Lo Speed Format or
Domestic Dialing Format.
3 – 2300 Hz
Reserved.
4 – No Handshake
No Handshake Tone is not recommended.
5 – Pager
Pager Handshake Tone is required to communicate
in Basic Pager Format.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Dialer Information
11.4
Transmission Format for Receiver 1
and Receiver 2
033 (Receiver 1)
Location
1
Contact ID
2
4 + 2 express
3
FSK 300 baud Bell
4
Domestic
5
Basic pager
073 (Receiver 2)
Location
1
Contact ID
2
4 + 2 express
3
FSK 300 baud Bell
4
Domestic
5
Basic pager
Select the desired transmission format here. These
locations select the data format used to transmit to
the base station receiver. These locations also allow
you to configure the control panel for domestic or
basic pager formats.
11.5
Subscriber ID Number for Receiver
1 and Receiver 2
Location
034 to 039 (Receiver 1)
Default
0
074 to 079 (Receiver 2)
Location
0
Default
The Subscriber ID Number is transmitted to identify
the calling control panel. Enter the Subscriber ID
Number in the six locations provided for each
receiver.
For Basic Pager Format, Locations 034 to 036 (for
Receiver 1) and Locations 074 to 076 (for Receiver 2)
are ignored and the first digit of the Subscriber ID
Number must start in Location 037 (Receiver 1) and
Location 077 (Receiver 2).
When using Domestic Dialing Format, the number of
identification beeps is determined by the value
programmed in Location 039 (Receiver 1) and
Location 079 (Receiver 2). This value allows the
identification of up to 15 different control panels that
call the same telephone number.
Example
To program the Subscriber ID Number as 4729, you
would program the six locations as:
[0 0 4 7 2 9]
EN | 50
