ICP-CC408 | Installation Guide | 12.0
12.0 Dialer Options
When programming these locations, there are up to
four options per location. You can select any
combination of the options by programming a single
value. Calculate this value by adding the option bit
numbers together. Refer to Section 2.3 Programming
Option Bits on page 11 for more information.
12.1
Dialer Options 1
177
Location
1
Dialer reporting functions allowed
2
Remote arming by telephone allowed
4
Answering machine bypass only when armed
8
Bell 103 used for FSK format (disabled = CCITT
V21)
1 – Dialer Reporting Functions Allowed
If you select this option, the dialer operates for all
functions.
If you do not select this option, the communication
dialer does not operate.
Upload/Download using the CC816 Alarm Link
Software and telephone remote arming remain
operational regardless of this setting.
2 – Remote Arming by Telephone Allowed
If you select this option, you can remotely arm the
system by pressing [*] on your touch-tone telephone.
Refer to Section 7.0 Remote Arming by Telephone on
page 41 for more information. Forced arming is
automatically assumed when this feature is used.
Refer to Section 14.3.7 Zone Options 2 on page 62 for
more information on forced arming.
Remote arming by telephone is not affected by
whether remote functions are enabled or disabled.
Refer to Section 11.10 Ring Count on page 51 for
programming the number of rings before the control
panel answers an incoming call.
4 – Answering Machine Bypass Only When Armed
Select this option to enable the Answering Machine
Bypass feature when the system is armed. When the
system is disarmed, the control panel does not
answer any incoming calls. This option is beneficial
in high telephone traffic installations where the
control panel could answer an incoming call. Refer to
Section 11.10 Ring Count on page 41 to program
Answering Machine Bypass.
8 – Use Bell 103 for FSK Format
(Disabled = CCITT V21)
If this option is selected, the control panel uses the
BELL 103 transmission frequency at 300 baud. If this
option is not selected, the control panel uses the
CCITT V21 transmission frequency at 300 baud.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Dialer Options
12.2
Dialer Options 2
178
Location
0
Default
1
Open/Close Reports only if previous alarm
2
Open/Close Reports for STAY Mode 1 and STAY
Mode 2
4
Delay siren until transmission complete
8
Extend handshake wait time from 30 sec to 60 sec
1 – Open/Close Reports Only if Previous Alarm
When selected, an Opening Report is transmitted to
the base station receiver when the system is disarmed
after an alarm occurred. When the system is armed, a
Closing Report is transmitted. An Opening or
Closing Report does not report again until the system
registers another alarm.
Open/Close Reports must be enabled in Locations
333 and 334 (refer to Section 15.6 Open/Close Reports
on page 65) for this option to work.
For a partitioned ICP-CC408 Control Panel, an
Open/Close Report is sent only for the area in which
the alarm occurred.
If the system is disarmed when an alarm
occurs, only a Closing Report is sent the
next time the system is armed.
2 – Open/Close Reports for STAY Mode 1 and
STAY Mode 2
Select this option if Open and Close Reports are
required when the system is armed in STAY Mode 1
or STAY Mode 2.
Open/Close Reports must be enabled in Locations
333 and 334 (refer to Section 15.6 Open/Close Reports
on page 65) for this option to work.
4 – Delay Siren until Transmission Complete
If this option is selected, the EDMSAT, horn speaker,
bell, and strobe outputs are not activated until after
the control panel sends the message and the base
station receiver sends a kiss-off back to the control
panel. If multiple messages are transmitted, the sirens
are activated after the last kiss-off is sent.
If a Codepad Panic, Codepad Fire, or Codepad
Medical Alarm is activated, the EDMSAT, horn
speaker, bell, and strobe outputs operate
immediately.
8 – Extend Time to Wait for Handshake from 30 to
55 Sec
By default, the control panel waits approximately 30
sec for receipt of a valid handshake tone after it dials
the monitoring station. The handshake tone indicates
to the control panel that it reached the monitoring
station and can now transmit its messages. Selecting
this option extends this wait time from 30 sec to 55
sec.
EN | 53
