ICP-CC408 | Installation Guide | 19.0
19.4.1
Zone Allocations for Area 1
434 to 441
Location
Area 1 – Zone 1 indicator
Area 1 – Zone 2 indicator
Area 1 – Zone 3 indicator
Area 1 – Zone 4 indicator
Area 1 – Zone 5 indicator
Area 1 – Zone 6 indicator
Area 1 – Zone 7 indicator
Area 1 – Zone 8 indicator
19.4.2 Zone Allocations for Area 2
Location
442 to 449
Area 2 – Zone 1 indicator
Area 2 – Zone 2 indicator
Area 2 – Zone 3 indicator
Area 2 – Zone 4 indicator
Area 2 – Zone 5 indicator
Area 2 – Zone 6 indicator
Area 2 – Zone 7 indicator
Area 2 – Zone 8 indicator
Example
In this example, Zones 1, 2, 3, and 4 are allocated to
Area 1 to appear as zones 1, 2, 3 and 4. Zones 1, 5, 6,
7, 8 are allocated to Area 2 to appear as zones 1, 5, 6,
7, and 8. Programming the same zone into more than
one area specifies that zone as a common zone.
Figure 14: Area 1 Codepad Display
Area 1 Zone Allocations
Locations 434 to 441: 1 2 3 4 0 0 0 0
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Partitioning
Figure 15: Area 2 Codepad Display
Location
Default
434
0
435
0
436
0
437
0
438
0
439
0
440
0
441
0
Area 2 Zone Allocations
Locations 442 to 449: 1 0 0 0 5 6 7 8
Location
Default
442
0
19.5
443
0
444
0
Location
445
0
446
0
User Code 1
447
0
User Code 2
448
0
User Code 3
449
0
User Code 4
User Code 5
User Code 6
User Code 7
User Code 8
User Code 9
User Code 10
User Code 11
User Code 12
User Code 13
User Code 14
User Code 15
User Code 16
Locations 450 to 465 are used to assign each User
Code to one or two area areas of a partitioned ICP-
CC408 Control Panel. Enter a value from 0 to 3 into
each of these locations to assign the User Code
holder to the areas it must operate (refer to Table 64).
You can allocate multiple User Codes to the same
area.
Table 64: User Code Allocations
Option
0
1
2
3
User Code Allocations
450 to 465
Location
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
Description
Not allocated to an area
Allocated to Area 1
Allocated to Area 2
Allocated to Area 1 and Area 2
EN | 84
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
