14.0 Zone Information

14.1

Day Alarm Information

Location
265
0
Default
1
Zone 1
2
Zone 2
4
Zone 3
8
Zone 4
This location has four programming options. You can
select any combination of the options by
programming a single value. Calculate this value by
adding the option bit numbers together. Refer to
Section 2.3 Programming Option Bits on page 11 for
more information.
Day Alarm allows some zones to be monitored when
the system is disarmed. Indications are available at
any of the programmable outputs, including the
codepad buzzer. This function accommodates
latching and non-latching Day Alarm Output Event
Types.
When the system is armed in AWAY Mode, STAY
Mode 1, or STAY Mode 2, zones programmed as
Day Alarm Zones activate the sirens and dialer just
as non-Day Alarm Zones do. When Day Alarm is
activated, it ignores any zone Pulse Count settings
programmed for that zone (that is, the zone Pulse
Count is only relevant when the system is armed).
Example
You can set up a Day Alarm at the front door of a
shop with a pressure mat or electronic beam that is
activated when a customer enters the shop. When a
customer walks on the pressure mat or breaks the
electronic beam, the codepad buzzer beeps.
14.1.1

Day Alarm Resetting

An output that is programmed for Day Alarm
Resetting operates when a zone programmed for Day
Alarm is activated. The output is reset after the zone
is resealed. This occurs only when the system is
disarmed. Refer to Output Event Type 0,14 Day Alarm
Resetting on page 70 for more information.
14.1.2

Day Alarm Latching

An output that is programmed for Day Alarm
Latching operates when a zone programmed for Day
Alarm is activated. The zone indicator and the
latching output is reset when [AWAY] is pressed.
This occurs only when the system is disarmed. Refer
to Output Event Type 0,15 Day Alarm Latching on page
70 for more information.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
Zone Information
14.1.3

Day Alarm Operation

If a zone is programmed for Day Alarm, the zone
can be isolated in the normal way so that it does not
register as a Day Alarm Zone when the system is
disarmed. You can only use Zones 1 to 4 as Day
Alarm Zones.
You can program the STAY indicator to indicate
whether Day Alarm is turned on or off by selecting
Option 8 in Location 428 (refer to Section 18.5
Consumer Options 1 on page 80). When Day Alarm is
on, the STAY indicator flashes once every three sec.
Zones 5 to 8 can be monitored by programming an
output to mimic a zone. Refer to Section 16.2 Output
Event Types on page 69 for more information on the
Output Event Types that you can program.
To turn Day Alarm on:
Press and hold [4] until three beeps sound.
To turn Day Alarm off:
Press and hold [4] until two beeps sound.
14.2

EOL Resistor Value

266
Location
0
No EOL
1
1K (brown, black, red)
2
1K5 (brown, green, red)
3
2K2 (red, red, red)
4
3K3 (orange, orange, black, brown) 1%
5
3K9 (orange, white, red)
6
4K7 (yellow, violet, red)
7
5K6 (green, blue, red)
8
6K8 (blue, grey, black, brown) 1%
9
10K (brown, black, orange)
10
12K (brown, red, orange)
11
22K (red, red, orange)
12
Reserved
13
Reserved
14
Reserved
15
Split EOL 1%
You can program the control panel for different EOL
(end of line) resistor values. This is a global
parameter that affects all zones simultaneously. This
feature allows you to install the ICP-CC408 Control
Panel at an existing site without changing the EOL
resistors. This feature also increases the security of
the system because eleven possible EOL resistor
values can be used, which makes it extremely
difficult to tamper with the system.
If you select split EOL resistors, the control panel
looks for four Burglary Zones (1 to 4) with 3K3 EOL
resistors and four 24-Hour Zones (5 to 8) consisting
of 6K8 resistors connected in parallel. The Zone 1
terminal on the PCB is the terminal for Zones 1
and 5.
EN | 56
