ICP-CC408 | Installation Guide | 6.0
If there was no alarm during the armed cycle,
holding down [0] a second time disarms the system
from STAY Mode 2. To enable single button
disarming from STAY Mode 2 using this hold-down
function, select Option 4 in Location 429.
If an alarm occurred or entry warning was activated,
a valid User Code is required to disarm the system.
For more information, refer to Section 6.1.4 Setting
STAY Mode 2 Zones on page 31 (using the Installer
Code function) or Section 6.2.6 Setting STAY Mode 2
Zones on page 37 (using the Master Code function).
STAY Mode 2 is not available on
partitioned ICP-CC408 Control Panels.
6.4.4
Horn Speaker Test
Holding down [1] until two beeps sound activates the
horn speaker for a 2-sec burst. No other sounding
device operates during this mode.
6.4.5
Bell Test
Holding down [2] until two beeps sound activates the
internal screamers for a 2-sec burst. No other
sounding device operates during this mode.
If the SS914 Satellite Siren (EDMSAT) is connected
to the control panel, this function tests both the horn
speaker and the strobe connected to the satellite siren
for a 2-sec burst.
6.4.6
Strobe Test
Holding down [3] operates the strobe. No other
device operates during this mode.
If the SS914 Satellite Siren (EDMSAT) is connected
to the control panel, this function also tests the strobe
on the satellite siren.
To turn the strobe test on:
Press and hold [3] until three beeps sound.
The strobe flashes.
To turn the strobe test off:
Press and hold [3] until two beeps sound.
The strobe stops flashing.
6.4.7
Turning Day Alarm On and Off
Holding down [4] turns Day Alarm on or off. If you
want the STAY indicator to indicate the status of Day
Alarm operation (enabled or disabled), select Option
8 in Location 428 (refer to Section 18.5 Consumer
Options 1 on page 80. When this option is selected,
the STAY indicator flashes once every 3 sec when
Day Alarm is active.
To turn Day Alarm on:
Press and hold [4] until three beeps sound.
To turn Day Alarm off:
Press and hold [4] until two beeps sound.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Functions
6.4.8
Fault Analysis Mode
There are a number of system faults that can be
detected by the control panel. When any of these
faults are present, the FAULT indicator flashes and
the codepad beeps once per min. Refer to Section
4.12 Fault Analysis Mode on page 23 for more
information on each fault type.
To determine the type of fault:
Press and hold [5] until two beeps sound.
The STAY, AWAY, and FAULT indicators flash.
One or more zone indicators (1 to 8) light to indicate
the type of fault that occurred. Refer to Table 18.
To exit from Fault Analysis Mode:
Press [AWAY].
The STAY and AWAY indicators are extinguished
and the system returns to the disarmed state.
6.4.9
Initiate a Modem Call
Holding down [6] until two beeps sound forces the
control panel to dial the callback telephone number
programmed in Locations 159 to 174 (refer to Section
11.9 Call Back Telephone Number on page 51) in an
attempt to connect to the installer's remote computer.
The remote computer must be running the CC816
Alarm Link Software and must be set to Waiting for
an Incoming Call. If no callback telephone number is
programmed, holding down [6] has no effect.
6.4.10
Reset Latching Outputs
Holding down [7] until two beeps sound resets any
output that is programmed to remain on after it is
activated.
The output must be programmed with a latching
polarity. Refer to Section 16.3 Output Polarity on page
73 for more information.
6.4.11
Codepad Buzzer Tone Change
Holding down [8] down continuously changes the
tone of the buzzer in the remote codepad. There are
fifty different tones from 1500 Hz to 5000 Hz. In an
installation with multiple codepads, you can set a
different tone for each codepad.
To change the buzzer tone:
1. Press and hold [8] continuously.
The tone of the buzzer increases in pitch.
2. Release [8] button when you hear the desired
tone.
Every time the system is powered down,
you must reset each codepad to its
individual tone using this function.
On partitioned ICP-CC408 Control Panels, this hold-
down function also indicates the area to which the
codepad belongs.
EN | 40
