ICP-CC408 | Installation Guide | 17.0
17.0 System Event Timers
This section covers the features that involve timing,
such as Entry and Exit Times, Sensor Watch Time,
Siren Run Time, and System Date and Time.
17.1
Programming Entry/Exit Timers
There are two programming locations for Entry
Timer 1, Entry Timer 2, Exit Time For AWAY
Mode, and Entry Guard Time For STAY Mode.
The first location of the timer allows you to set the
timer in increments of 1 sec. The second location
allows you to set the timer in increments of 16 sec.
Add these two locations together for the total time.
Example
To set the Entry Time to 18 sec, program Location
410 as 2 (2 x 1 sec = 2 sec) and Location 411 as 1
(1 x 16 sec = 16 sec) for a total time of 18 sec
(2 + 16 = 18).
17.2
Entry Timer 1
Location
398 to 399
Increments of 1 sec
(0 sec to 15 sec)
Increments of 16 sec
(0 sec to 240 sec)
You can program Entry Timer 1 from 0 to 255 sec in
increments of 1 sec. Entry Timer 1 is the delay time
used by the Delay-1 Zones. Refer to Section 14.3.2
Zone Types on page 58 for more information.
17.3
Entry Timer 2
400 to 401
Location
Increments of 1 sec
(0 sec to 15 sec)
Increments of 16 sec
(0 sec to 240 sec)
You can program Entry Timer 2 from 0 to 255 sec in
increments of 1 sec. Entry Timer 2 is the delay time
used by Delay-2 Zones. Refer to Section 14.3.2 Zone
Types on page 58 for more information.
17.4
Exit Time
Location
402 to 403
Increments of 1 sec
(0 sec to 15 sec)
Increments of 16 sec
(0 sec to 240 sec)
You can program the Exit Timer from 0 to 255 sec in
increments of 1 sec. When arming the system in
AWAY Mode, the remote codepad beeps during
Exit Time until the final 10 sec, when the codepad
sounds one continuous beep to indicate the end of
Exit Time is near.
Bosch Security Systems, Inc. | 12/08 | F01U089463-02
System Event Timers
The remote codepad always sounds one short beep
at the end of Exit Time when arming in STAY Mode
1 or STAY Mode 2.
17.5
Location
Increments of 1 sec
(0 sec to 15 sec)
Increments of 16 sec
(0 sec to 240 sec)
Entry Guard Timer for STAY Mode is the delay time
used for all zones except 24-Hour Burglary and
24-Hour Fire Zones when the system is armed in
STAY Mode 1 or STAY Mode 2. All zones,
including Delay Zones, use this timer for the entry
delay (for example, the Entry Guard Timer overrides
the delay time programmed for a Delay Zone). If the
Entry Guard Timer is programmed as 0, each zone
acts according to its programmed zone type.
17.6
Location
Location
Default
Increments of 1 sec (0 sec to
398
4
15 sec)
Increments of 16 sec (0 sec to
399
1
240 sec)
These locations program the time in sec that a
delayed report waits dormant in the dial buffer
before it is sent to the receiving party. If a User Code
holder resets the alarm within this time frame, the
control panel clears the dialer buffer and does not
report the alarm to the receiving party. Refer to
Section 14.3.5 Zone Options 1 on page 60 to program
zones for delay alarm reporting.
Location
Default
17.7
400
8
Location
401
2
Increments of days (tens digit)
Increments of days (units digit)
The time set in these two locations determines the
number of days (0 to 99) a zone can remain sealed
before registering as a fault. This feature is active
only when the system is disarmed. If a zone
programmed for Sensor Watch is not unsealed and
reset during this time, the FAULT indicator lights.
Location
Default
Refer to Section 4.13 Fault Descriptions on page 24 for
402
12
more information on Sensor Watch Faults. Refer to
Section 14.3.5 Zone Options 1 on page 60 for
403
3
programming zones for Sensor Watch.
The Sensor Watch Time counter is active only when
the control panel is disarmed. If the system is
disarmed for 8 hours a day and the Sensor Watch
Time is programmed for 1 day, a zone programmed
for Sensor Watch registers a Sensor Watch Fault if it
is not activated while disarmed within 3 days.
Entry Guard Timer for STAY Mode
404 to 405
Location
404
405
Delay Alarm Reporting Time
406 to 407
Location
406
407
Sensor Watch Time
408 to 409
Location
408
409
EN | 76
Default
0
0
Default
0
0
Default
0
0
