Troubleshooting

Belt Driven Groomer (Optional): General Information
Problem
The groomer reel does not
rotate.
The turf is damaged or has
uneven grooming.
Possible Causes
Seized grooming reel or idler
bearing(s) in groomer side
plate(s).
Broken or damaged drive belt
idler spring.
The groomer drive belt is
worn, broken or damaged.
The groomer is set too
aggressively.
The groomer reel blades are
bent, damaged, or missing.
The groomer reel shaft is bent
or damaged.
Grooming depth is not equal
on both ends of the groomer
reel.
Page 8–4
Correction
Identify and replace faulty
bearing(s).
Replace idler .
If the belt slips, it probably is
worn and must be replaced.
Repair or replace belt if
necessary. A broken or worn
belt could be the result of
improper belt routing or seized
bearings in groomer assembly.
Refer to groomer Installation
Instructions for groomer set-up
information.
Repair or replace the blades if
necessary.
Replace the groomer reel
shaft.
Adjust the depth if necessary.
Check and adjust the cutting
unit set up (level bed knife to
reel, level rear roller to reel,
set the height-of-cut, etc.).
