CDM-625 Advanced Satellite Modem
Front Panel Operation
5.9.5

Utilities: 1:N

1:N communications:
If the unit is attached to a CRS-300 switch as part of a 1:N system, it needs to be configured for
1:N communication.
5.9.6

Utilities: Circuit ID

Edit this Modem's Circuit ID:
----------------------------------------
This menu allow the user to enter a Circuit ID string. Only the bottom line is available (40
characters). Use the
edit the character using
Space ( ) * + - , . / 0-9 and A-Z.
When the user has composed the string, press ENTER.
5.9.7

Utilities: Firmware

THESE MENUS ARE FOR DIAGNOSTIC PURPOSES. ONLY CHANGE AN IMAGE
IF INSTRUCTED TO DO SO BY A COMTECH EF DATA CUSTOMER SUPPORT
TECHNICIAN.
IMPORTANT
This series of submenus permits the user to view information about the CDM-625 internal
firmware. The modem can store two complete firmware images, and the user can select which
image will be loaded the next time the unit reboots.
Firmware Images:
Select Info or Select using the
5.9.7.1 Utilities: Firmware
Firmware Information:
◄ ►
Use the arrow keys and ENTER key to select and view information about the Bootrom, the
two firmware images, e.g.:
Enabled (Enable,Disable)
◄ ► arrow keys to position the cursor on to the character to be edited, then
arrow keys. The following characters are available:
▲ ▼
Info Select
◄ ►
arrow keys, then press ENTER.
Info
Boot-ROM Image#1
MN-0000036 (Ref MN/CDM625.IOM)
Image#2
5–59
Revision 1
(v)
(34v)
(34)
(34)
