CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Rx Spectrum RSI= 1 byte, 0 or 1
Invert
Rx RDS= 1 byte, 0 or 1
Descrambler
Rx Demod RSW= 3 bytes
Acquisition
Sweep Width
Exception:
600/L
2 bytes
Rx Clock RCK= 1 byte, value
Source of 0 thru 3
Rx Clock RCI= 1 byte, value 0
Invert or 1
Description of Arguments
Command or Query.
Rx Spectrum Invert, where:
0=Normal
1=Rx Spectrum Invert
Example: RSI=0 (selects Normal)
Command or Query.
Rx Descrambler state, where:
0=Off
1=Normal
2=IESS-315 when in Turbo mode
Example: RDS=1 (Scrambler On)
Command or Query.
Rx ± acquisition sweep range of demodulator, in kHz. Available
range depends on the symbol rate:
± 1 to the symbol rate (ksps)
18ksps to 32ksps:
± 1 to 32 kHz
32ksps to 389ksps:
389ksps to 2000ksps: ± 1 to 10% of sym rate
± 1 to 200 kHz
>2000ksps:
Example: RSW=009 (selects ± 9 kHz)
Command or Query.
Rx Clock Source, where:
0=Rx Satellite
1=Tx-Terrestrial
2=Internal(SCT)
3=INSERT (command valid only when Rx framing is Insert or
D&I++ and interface is G.703 or set for D&I loop.
Example: RCK=1 (selects Tx-Terrestrial)
Command or Query.
Invert Receive Clock, where x may be:
0=Normal
1=Inverted
D–20
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction Response to Query
Command
& Qualifier)
RSI= RSI? RSI=x
RSI? (see description of
arguments)
RSI*
RSI#
RDS= RDS? RDS=x
RDS? (see description of
arguments)
RDS*
RDS#
RSW= RSW? RSW=xxx
RSW? (see description of
arguments)
RSW*
RSW#
RCK= RCK? RCK=x
RCK? (see description of
arguments)
RCK*
RCK#
RCI= RCI? RCI=x
RCI? (see description of
RCI* arguments)
RCI#
Revision 1
