CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Statistics
SSI=
1 byte,
Sample
numerical
Interval
Number of
N/A
3 bytes
Unread stored
Statistics
Retrieve next
N/A
135 bytes
5 unread
Stored
Statistics
Clear All
CAS=
None
Stored
Statistics
Description of Arguments
Command or Query.
Used to set the sample interval for the Statistics Logging Function,
where x= 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging
function.
Example: SSI=3 means 30 minutes
Query only.
Unit returns the number of stored Statistics, which remain Unread
(over remote control),
in the form xxx (0-255).
Example: NUS=187
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been
read over the remote control.
Reply format: [CR]sub-body[CR]sub-body[CR]sub-body[CR]sub-
body[CR]sub-body,
where Sub-body=AA.ABB.BC.CD.Dddmmyyhhmmss,
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyy = date stamp.
hhmmss = time stamp.
If there are no new events, the unit replies with RNS*. If there are
less than 5 statistics to be retrieved, the remaining positions are
padded with zeros.
Command only.
Forces the software to clear the software statistics log.
Example: CAS=
Note: This command takes no arguments.
D–31
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction
Response to Query
Command
& Qualifier)
SSI=
SSI?
SSI=x
SSI?
(see description for
details of argument)
SSI*
SSI#
N/A
NUS?
NUS=xxx
(see description of
arguments)
N/A
RNS?
RNS=[CR]AA.ABB.BC.
CD.Dddmmyyhhmmss[
CR]AA.ABB.BC.CD.Dd
dmmyyhhmmss[CR]AA
.ABB.BC.CD.Dddmmy
yhhmmss[CR]AA.ABB.
BC.CD.Dddmmyyhhm
mss[CR]AA.ABB.BC.C
D.Dddmmyyhhmmss
(see description for
details of arguments)
CAS=
N/A
N/A
CAS?
CAS*
CAS#
Revision 1
