CDM-625 Advanced Satellite Modem
Front Panel Operation
5.4

SELECT: Configuration

CONFIG:
CnC
◄ ►
Use the arrow keys to select from the submenu choices shown, then press ENTER. The
submenus available from the Configuration menu are as follows:
Submenu
All
Mode
Tx
Rx
Clocks
D&I
CnC
EDMAC
Misc
Mask
Remote
IP
IMPORTANT
All Mode
EDMAC Misc
Description
Permits the user to completely configure the unit, being prompted, step by step,
to make choices, or edit data. This is highly recommended for new users, as it
will clearly lead the user through all the configuration parameters.
Permits the user to select Frame Type and Data Format for Tx and Rx.
(Transmit) Permits the user to define, on a parameter-by-parameter basis, the
Tx configuration of the unit. These menu submenu branches would be used if the
user wished to change, for example, just the Tx Frequency.
(Receive) Permits the user to define, on a parameter-by-parameter basis, the Rx
configuration of the unit. These menu submenu branches would be used if the
user wished to change, for example, just the Rx data rate.
Permits the user to select Tx-Clocking, Rx-Buffer/Clock, or External Reference.
Permits the user to select (Quad) Drop & Insert options.
®
(DoubleTalk Carrier-in-Carrier
®
Carrier-in-Carrier
Permits the user to select EDMAC options.
(Miscellaneous) Permits the user to select, view, or change various other
parameters.
Permits the user to activate or MASK an alarm condition.
(Remote Control) Permits the user to define whether the unit is being controlled
locally, remotely, or via IP, and to configure the serial Remote Control
parameters: baud rate, I/O format, address.
Permits the user to configure various IP parameters, including IP address,
gateway and MAC addresses.
Only one method of remote access may control the modem at a time. The
modem may be monitored over the remote control bus at any time (i.e.,
queries only), and the front panel may be viewed.
To make configuration parameter changes from the front panel, local
mode is required. Via serial remote, remote mode is required, and via IP,
Ethernet remote is required.
Tx Rx Clocks
Mask Remote
®
) Permits the user to select DoubleTalk
(CnC) options.
5–7
MN-0000036 (Ref MN/CDM625.IOM)
D&I
IP (34)
Revision 1
®
