CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Rx Eb/No
N/A
4 bytes
Redundancy
N/A
1 byte, 0 or 1
State
Temperature
N/A
3 bytes
Offline Unit
N/A
6 bytes
Status
Description of Arguments
Query only.
Unit returns the value of Eb/No, between 0 to 16 dB.
Format xx.x, resolution 0.1 dB.
Returns 99.9 if demod is unlocked.
Returns +016 for values greater than 16.0 dB.
Example: EBN=12.3 (which is Eb/No = 12.3 dB)
Query only.
Unit returns the redundancy state of the unit, where
0=Offline
1=Online
Example: RED=1 (which is Online)
Query only.
Unit returns the value of the internal temperature sensor, in the
form of xxx (degrees C).
Example: TMP=+26
Query only. (1:1 set-up)
This query is sent to the online modem of a 1:1 pair. It provides
access to the fault status information (FLT?) of the offline modem.
This is the only way to interrogate the status of an offline modem
at the distant-end of a link.
The response format may be:
No1for1
which indicates that no 1:1 system has been
detected. Presence of a 1kHz signal from the CRS-150
is used to indicate a 1:1 set-up.
NoComm which indicates that a 1kHz signal has been
detected, but that there is no (or not yet) a response
for the modem, or.
abcdef which is the FLT? response information from
the offline 600/L unit.
abcdefghxx which is the FLT? response information from the
offline 625 unit.
D–50
Revision 1
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction &
Response to Query
Command
Qualifier)
N/A
EBN?
EBN=xxxx
(see description of
arguments)
N/A
RED?
RED=x
(see description
of arguments)
N/A
TMP?
TMP=xxx
(see description of
arguments)
N/A
OUS?
OUS=xxxxxx
(see description of
arguments)
