Data Rate Ranges - Comtech EF Data CDM-625 Installation And Operation Manual

CDM-625 Advanced Satellite Modem
Introduction
1.7.7

Data Rate Ranges

UNFRAMED, NO REED SOLOMON
No FEC, BPSK
No FEC, O/QPSK
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
TRELLIS, 8-PSK, 2/3
TPC, BPSK, 5/16
TPC, BPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 3/4
TPC, O/QPSK, 17/18 (aka 0.95)
TPC, O/QPSK, 7/8
TPC, 8-PSK/8-QAM, 3/4
TPC, 8-PSK/8-QAM, 17/18 (aka 0.95)
TPC, 8-PSK/8-QAM, 7/8
TPC, 16-QAM, 3/4
TPC, 16-QAM, 7/8
LDPC, BPSK, 1/2
LDPC, O/QPSK, 1/2
LDPC, QPSK, 3/4
LDPC, QPSK, 2/3
LDPC, 8-PSK/8-QAM, 3/4
LDPC, 8-PSK/8-QAM, 2/3
LDPC, 16-QAM, 3/4
UNFRAMED, ANY REED SOLOMON
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
TRELLIS, 8-PSK, 2/3
VIT 16-QAM, 3/4
VIT 16-QAM, 7/8
EDMAC or EDMAC-2, NO REED SOLOMON
No FEC, BPSK
No FEC, O/QPSK
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
TRELLIS, 8-PSK, 2/3
TPC, BPSK, 5/16
TPC, BPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 21/44 (aka 1/2)
MN-0000036 (Ref MN/CDM625.IOM)
Lower Limit (kbps) Upper Limit (kbps)
18.0
36.0
18.0
18.0
27.0
31.5
36.0
18.0
18.0
18.0
27.0
34.2
31.5
40.0
52.0
48.0
54.0
63.0
18.0
18.0
27.0
24.0
40.5
36.0
54.0
Lower Limit (kbps) Upper Limit (kbps)
18.0
18.0
27.0
31.5
36.0
54.0
63.0
Lower Limit (kbps) Upper Limit (kbps)
18.0
35.5
18.0
18.0
26.6
31.0
35.5
18.0
18.0
18.0
1–18
Revision 1
12500
25000.0
6250.0
12500.0
18750.0
21875.0
25000.0
3906.2
5965.9
11931.8
18750.0
23611.1
21875.0
25000.0
25000.0
25000.0
25000.0
25000.0
6250.0
12500.0
18750.0
16666.6
25000.0
25000.0
25000.0
5555.0
11111.0
16666.7
19444.0
22222.0
25000.0
25000.0
12295.0
24590.1
6147.5
12295.0
18442.6
21516.3
24590.1
3842.2
5868.1
11736.2
